Toyota Sienta
2015-06 → 2022-07 · chassis NCP175,NHP170,NSP17# · catalogue 119130 · Japan
Supported model
Data version 2023-09
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 11434B — Pin, Straight(FOR CLUTCH HOUSING SET) | ||||
| 90250-10113 note |
Pin, Straight(FOR CLUTCH HOUSING SET)
2015-06 → 2018-09
ended
|
2NRFKE NSP17# | ¥120 | |
| 90250-10113 note |
Pin, Straight(FOR CLUTCH HOUSING SET)
2018-09 → 2022-07
ended
|
2NRFKE NSP17# | ¥120 | |
| 12101L — Gasket NO.1(FOR OIL PAN) | ||||
| 90430-12039 |
Gasket NO.1(FOR OIL PAN)
2015-06 → 2018-09
ended
|
2NRFKE NSP17# | ¥80 | |
| 90430-12039 |
Gasket NO.1(FOR OIL PAN)
2018-09 → 2022-07
ended
|
2NRFKE NSP17# | ¥80 | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
