Toyota Sienta

2015-06 → 2022-07 · chassis NCP175,NHP170,NSP17# · catalogue 119130 · Japan

Supported model Data version 2023-09
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes
Exploded illustration 152329C 1106 — not listed in this catalogue 1105 — not listed in this catalogue 1105 — not listed in this catalogue 1105 — not listed in this catalogue 15104 — STRAINER SUB-ASSY, OIL (4 parts) 15104A — RING, O(FOR OIL STRAINER) (2 parts) 15100B — RING, O(FOR OIL PUMP) (2 parts)
152329C · 3 callouts, 4 unlisted Full size ↗
Dashed callouts are standard fasteners the factory draws but does not list as separate parts — there is no part number behind them.
8 parts on this figure
Part number Description Fitment Price
15100B — Ring, O(FOR OIL PUMP)
90301-27014 Ring, O(FOR OIL PUMP)
2015-06 → 2018-09 ended
2NRFKE NSP17# ¥200
90301-27014 Ring, O(FOR OIL PUMP)
2018-09 → 2022-07 ended
2NRFKE NSP17# ¥200
15104 — Strainer Sub-assy, Oil
15104-21022 Strainer Sub-assy, Oil
2015-06 → 2018-09 ended
1NZ# NCP175,NHP170 ¥1,960
15104-47060 Strainer Sub-assy, Oil
2015-06 → 2018-09 ended
2NRFKE NSP17# ¥170
15104-21022 Strainer Sub-assy, Oil
2018-09 → 2022-07 ended
1NZ# NCP175,NHP170 ¥1,960
15104-47060 Strainer Sub-assy, Oil
2018-09 → 2022-07 ended
2NRFKE NSP17# ¥170
15104A — Ring, O(FOR OIL STRAINER)
96723-19018 Ring, O(FOR OIL STRAINER)
2015-06 → 2018-09 ended
2NRFKE NSP17# ¥130
96723-19018 Ring, O(FOR OIL STRAINER)
2018-09 → 2022-07 ended
2NRFKE NSP17# ¥130
No quantity column: the factory catalogue records which parts a vehicle takes, never how many.
