Toyota Sienta
2015-06 → 2022-07 · chassis NCP175,NHP170,NSP17# · catalogue 119130 · Japan
Supported model
Data version 2023-09
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 81080J — Lamp Assy, Interior Illumination, NO.1 | ||||
| 81080-52010 |
Lamp Assy, Interior Illumination, NO.1
2015-06 → 2018-09
ended
|
NSP172 | ¥770 | |
| 81080-52010 |
Lamp Assy, Interior Illumination, NO.1
2018-09 → 2022-07
ended
|
NSP172 | ¥770 | |
| 81240 — Lamp Assy, Room, NO.1 | ||||
| 81240-35020-B0 note |
Lamp Assy, Room, NO.1
2015-06 → 2018-09
ended
|
NCP175,NHP170,NSP17# | ¥2,460 | |
| 81240-35020-B0 note |
Lamp Assy, Room, NO.1
2018-09 → 2019-09
ended
|
NCP175,NHP170,NSP170 G | ¥2,460 | |
| 81240-35020-B0 note |
Lamp Assy, Room, NO.1
2018-09 → 2019-09
ended
|
NHP170,NSP170 FNBSG | ¥2,460 | |
| 81240-35020-B0 note |
Lamp Assy, Room, NO.1
2018-09 → 2019-09
ended
|
NCP175,NHP170,NSP17# WKG,WKX,X | ¥2,460 | |
| 81240-35020-B0 note |
Lamp Assy, Room, NO.1
2018-09 → 2019-09
ended
|
NCP175,NHP170,NSP170 FNBSX,GCERO | ¥2,460 | |
| 81240-42020-B0 note |
Lamp Assy, Room, NO.1
2019-09 → 2022-07
ended
|
NHP170,NSP170 FNBSG | ¥2,230 | |
| 81240-42020-B0 note |
Lamp Assy, Room, NO.1
2019-09 → 2022-07
ended
|
NCP175,NHP170,NSP170 FNBSX,FNGCR,GCERO | ¥2,230 | |
| 81240-42020-B0 note |
Lamp Assy, Room, NO.1
2019-09 → 2022-07
ended
|
NCP175,NHP170,NSP17# WKG,WKX,X | ¥2,230 | |
| 81240-42020-B0 note |
Lamp Assy, Room, NO.1
2019-09 → 2022-07
ended
|
NCP175,NHP170,NSP170 G | ¥2,230 | |
| 81240B — Bulb, Room Lamp, NO.1 | ||||
| 90981-14011 note |
Bulb, Room Lamp, NO.1
2015-06 → 2018-09
ended
|
NCP175,NHP170,NSP17# | ¥180 | |
| 90981-14011 note |
Bulb, Room Lamp, NO.1
2018-09 → 2022-07
ended
|
NCP175,NHP170,NSP17# | ¥180 | |
| 81260A — Lamp Assy, Map | ||||
| 81260-68010-B2 note |
Lamp Assy, Map
2015-06 → 2017-10
ended
|
NCP175,NHP170,NSP17# | ¥6,500 | |
| 81260-68011-B2 note |
Lamp Assy, Map
2017-11 → 2018-09
ended
|
NCP175,NHP170,NSP17# | ¥5,400 | |
| 81260-68011-B2 note |
Lamp Assy, Map
2018-09 → 2022-07
ended
|
NCP175,NHP170,NSP170 G | ¥5,400 | |
| 81260-68011-B2 note |
Lamp Assy, Map
2018-09 → 2022-07
ended
|
NCP175,NHP170,NSP170 FNBSX,FNGCR,GCERO | ¥5,400 | |
| 81260-68011-B2 note |
Lamp Assy, Map
2018-09 → 2022-07
ended
|
NCP175,NHP170,NSP17# WKG,WKX,X | ¥5,400 | |
| 81260-68011-B2 note |
Lamp Assy, Map
2018-09 → 2022-07
ended
|
NHP170,NSP170 FNBSG | ¥5,400 | |
| 81260C — Bulb(FOR MAP LAMP) | ||||
| 90981-11062 note |
Bulb(FOR MAP LAMP)
2015-06 → 2018-09
ended
|
NCP175,NHP170,NSP17# | ¥340 | |
| 90981-11062 note |
Bulb(FOR MAP LAMP)
2018-09 → 2022-07
ended
|
NCP175,NHP170,NSP17# | ¥340 | |
| 81330 — Lamp Assy, Luggage Compartment, NO.1 | ||||
| 81250-30210 |
Lamp Assy, Luggage Compartment, NO.1
2015-06 → 2018-09
ended
|
NCP175,NHP170,NSP170 | ¥1,250 | |
| 81250-30210 |
Lamp Assy, Luggage Compartment, NO.1
2015-06 → 2018-09
ended
|
NSP172 | ¥1,250 | |
| 81250-30210 |
Lamp Assy, Luggage Compartment, NO.1
2018-09 → 2022-07
ended
|
NCP175,NHP170,NSP170 06S,07S | ¥1,250 | |
| 81250-30210 |
Lamp Assy, Luggage Compartment, NO.1
2018-09 → 2022-07
ended
|
NSP172 | ¥1,250 | |
| 81330-58010 |
Lamp Assy, Luggage Compartment, NO.1
2018-09 → 2022-07
ended
|
NHP170,NSP170 05S | ¥460 | |
| 81330B — Bulb, Luggage Compartment Lamp | ||||
| 99132-12050 note |
Bulb, Luggage Compartment Lamp
2015-06 → 2018-09
ended
|
NCP175,NHP170,NSP170 | ¥110 | |
| 99132-12050 note |
Bulb, Luggage Compartment Lamp
2015-06 → 2018-09
ended
|
NSP172 | ¥110 | |
| 99132-12050 note |
Bulb, Luggage Compartment Lamp
2018-09 → 2022-07
ended
|
NCP175,NHP170,NSP170 | ¥110 | |
| 99132-12050 note |
Bulb, Luggage Compartment Lamp
2018-09 → 2022-07
ended
|
NSP172 | ¥110 | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
