Toyota Starlet
1978-02 → 1984-09 · chassis KP6# · catalogue 121120 · Japan
Discontinued model
Data version 1985-03
Mirror
17 part groups · 3 illustrations
Part groups
| PNC | Description |
|---|---|
| 84870 | Switch Assy, Outer Mirror |
| 87810 | Mirror Assy, Inner Rear View |
| 87827 | Absorber, Inner Rear View Mirror |
| 87901B | Mirror Sub-assy, Outer Rear View, RH |
| 87904 | Spring Sub-assy, Outer Mirror, RH |
| 87906 | Spring Sub-assy, Outer Mirror, LH |
| 87906B | Mirror Sub-assy, Outer Rear View, LH |
| 87908 | Actuator Assy, Outer Mirror, RH |
| 87909 | Actuator Assy, Outer Mirror, LH |
| 87910 | Mirror Assy, Outer Rear View, RH |
| 87911 | Gasket, Outer Rear View Mirror, RH |
| 87914A | Cover, Outer Mirror Knob |
| 87918 | Knob, Control Outer Mirror |
| 87928 | Retainer, Outer Rear View Mirror, RH |
| 87929 | Retainer, Outer Rear View Mirror, LH |
| 87940 | Mirror Assy, Outer Rear View, LH |
| 87941 | Gasket, Outer Rear View Mirror, LH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
