Toyota Porte
2004-07 → 2012-06 · chassis NNP1# · catalogue 123110 · Japan
Supported model
Data version 2012-07
Instrument Panel & Glove Compartment
34 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 55301 | Panel Sub-assy, Instrument |
| 55303B | Panel Sub-assy, Instrument, Lower |
| 55306B | Brace Sub-assy, Instrument Panel TO Cowl |
| 55312A | Clip, Instrument Panel |
| 55330B | Reinforcement Assy, Instrument Panel |
| 55343B | Brace, Instrument Panel TO Cowl, Center |
| 55345A | Clip, Instrument Panel, NO.1 |
| 55355 | Cushion, Instrument Panel, NO.1 |
| 55357B | Cushion, Instrument Panel, NO.3 |
| 55376 | Bracket, Instrument Panel Mounting, NO.1 |
| 55405B | Panel Sub-assy, Instrument Cluster Finish, Center |
| 55406B | Panel Sub-assy, Instrument Cluster Finish, Lower Center |
| 55406D | Clip(FOR PANEL, INSTRUMENT CLUSTER FINISH) |
| 55411G | Panel, Instrument Cluster Finish, NO.1 |
| 55412D | Panel, Instrument Cluster Finish, Center |
| 55423D | Plate, Meter Hood Set |
| 55432B | Panel, Instrument Panel Finish, Lower |
| 55434B | Panel, Instrument Panel Finish, Lower Center |
| 55440D | Box Assy, Instrument Panel |
| 55444A | Spring, Instrument Panel Box |
| 55445B | Plate, Instrument Panel Finish |
| 55479C | Clip(FOR INSTRUMENT LOWER COVER) |
| 55501A | Door Sub-assy, Glove Compartment |
| 55521C | Cover, Stereo Opening |
| 55539 | Cover, Spare Switch Hole |
| 55547F | Cover, Remote Control Mirror Hole |
| 55606 | Cover Sub-assy, Instrument Panel Under, NO.1 |
| 55620C | Holder, Instrument Panel Cup |
| 55660 | Register Assy, Instrument Panel, NO.2 |
| 55660C | Register Assy, Instrument Panel |
| 55660D | Register Assy, Instrument Panel, NO.1 |
| 55670 | Register Assy, Instrument Panel, NO.3 |
| 73960A | Airbag Assy, Instrument Panel Passenger W/O Door |
| 89279J | Cover |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
