Toyota Porte/Spade
2012-07 → 2020-12 · chassis NCP14#,NSP14# · catalogue 123120 · Japan
Supported model
Data version 2022-07
Mat & Carpet
18 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 58312G | Board, Floor, Lwr |
| 58312H | Clip, Floor Board |
| 58313M | Board, Floor, Lwr NO.2 |
| 58510C | Carpet Assy, Front Floor, Front |
| 58520C | Clip(FOR FRONT FLOOR CARPET) |
| 58521F | Hook, Floor Carpet |
| 58522D | Hook, Floor Carpet, NO.2 |
| 58586C | Pad, Front Floor, Rear NO.2 LH |
| 58593 | Moulding, Floor Carpet, NO.1 |
| 58594B | Moulding, Floor Carpet, NO.2 |
| 58605D | Pad Sub-assy, Front Floor Silencer, Front RH |
| 58606D | Pad Sub-assy, Front Floor Silencer, Front LH |
| 58607C | Pad Sub-assy, Front Floor Silencer, Rear RH |
| 58608B | Pad Sub-assy, Front Floor Silencer, Rear LH |
| 58609 | Sheet Sub-assy, Rear Floor Silencer |
| 67731G | Spacer, Side Trim, NO.1 |
| 75498F | Clip, Side Trim, NO.1 |
| 87125E | Grille, Heater Air Outlet |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
