Toyota Aqua
2011-12 → 2021-06 · chassis NHP10 · catalogue 125110 · Japan
Supported model
Data version 2022-07
Front Seat & Seat Track
158 part groups · 20 illustrations
Illustrations
Part groups
| PNC | Description |
|---|---|
| 51980D | Hook Assy, Pintle, LH |
| 58561H | Carpet, Front Floor Side, LH |
| 71013S | Frame Sub-assy, Front Seatback, RH |
| 71014S | Frame Sub-assy, Front Seatback, LH |
| 71051A | Spring Sub-assy, Front Seat Cushion, RH |
| 71052A | Spring Sub-assy, Front Seat Cushion, LH |
| 71053S | Spring Sub-assy, Front Seatback, RH |
| 71054S | Spring Sub-assy, Front Seatback, LH |
| 71071S | Cover, Front Seat Cushion, RH(FOR SEPARATE TYPE) |
| 71072S | Cover, Front Seat Cushion, LH(FOR SEPARATE TYPE) |
| 71073S | Cover, Front Seatback, RH(FOR SEPARATE TYPE) |
| 71074S | Cover, Front Seatback, LH(FOR SEPARATE TYPE) |
| 71120B | Frame Assy, Front Seat W/Adjuster, LH |
| 71131B | Plate, Front Seat Cushion, NO.1 |
| 71138 | Spacer, Front Seat Set |
| 71139Z | Cover, Front Seat Leg, LH |
| 71148U | Cover, Front Seat Leg, Outer NO.1(FOR LH SEAT) |
| 71148W | Cover, Front Seat Leg, Outer NO.2(FOR LH SEAT) |
| 71148Y | Cover, Front Seat Leg, Outer LH |
| 71301F | Link Sub-assy, Rear Seat Cushion, LH |
| 71302E | Stopper Sub-assy, Rear Seat Leg |
| 71361E | Bracket, Front Seat Set, NO.1 Front Outer(FOR LH SEAT) |
| 71361G | Bracket, Front Seat Set, NO.1 Rear Outer(FOR LH SEAT) |
| 71362B | Bracket, Front Seat Set, NO.2 Rear Inner(FOR LH SEAT) |
| 71430C | Clip |
| 71511S | Pad, Front Seat Cushion, RH(FOR SEPARATE TYPE) |
| 71512S | Pad, Front Seat Cushion, LH (FOR SEPARATE TYPE) |
| 71517A | Pad, Front Seat Cushion Cover |
| 71537D | Protector, Front Seat Cushion Edge, LH |
| 71537E | Protector, Front Seat Cushion, NO.1 |
| 71537G | Protector, Front Seat Cushion Edge, RH(FOR RH SEAT) |
| 71537H | Protector, Front Seat Cushion Edge, RH(FOR LH SEAT) |
| 71538A | Protector, Front Seat Cushion Edge, LH(FOR RH SEAT) |
| 71538B | Protector, Front Seat Cushion Edge, LH(FOR LH SEAT) |
| 71551S | Pad, Front Seatback, RH(FOR SEPARATE TYPE) |
| 71552S | Pad, Front Seatback, LH(FOR SEPARATE TYPE) |
| 71587 | Protector, Front Seatback Edge |
| 71610S | Spring Assy, Front Seat Cushion, RH(FOR SEPARATE TYPE) |
| 71620S | Spring Assy, Front Seat Cushion, LH(FOR SEPARATE TYPE) |
| 71630S | Spring Assy, Front Seatback, RH(FOR SEPARATE TYPE) |
| 71640S | Spring Assy, Front Seatback, LH(FOR SEPARATE TYPE) |
| 71708D | Strap Sub-assy, Seat Cover, LH |
| 71731Q | Fastener, Seat Cover, LH |
| 71739H | Cushion, Seat Support, LH NO.1 |
| 71739J | Cushion, Seat Support, LH NO.2 |
| 71739K | Cushion, Seat Support, LH NO.3 |
| 71739L | Cushion, Seat Support, LH NO.4 |
| 71739M | Cushion, Seat Support, LH NO.5 |
| 71759B | Hook, Front Seatback |
| 71759D | Hook, Front Seatback, NO.2 |
| 71811D | Shield, Front Seat Cushion, RH |
| 71812D | Shield, Front Seat Cushion, LH |
| 71821A | Clip (FOR FRONT SEAT SIDE SHIELD) |
| 71832B | Cover, Front Seat Hinge, LH |
| 71848A | Cap, Seat Adjuster Cover, RH |
| 71849 | Cap, Seat Adjuster Cover, LH |
| 71861 | Shield, Front Seat Cushion, Inner RH |
| 71862 | Shield, Front Seat Cushion, Inner LH |
| 71873 | Shield, Front Seat Cushion, Lower RH |
| 71873A | Shield, Front Seat Cushion, Lower |
| 71874 | Shield, Front Seat Cushion, Lower LH |
| 71875G | Cover, Reclining Adjuster Inside, RH (FOR LH SEAT) |
| 71875H | Cover, Reclining Adjuster Inside, RH (FOR LH SEAT) |
| 71876C | Cover, Reclining Adjuster Inside, LH |
| 71876G | Cover, Reclining Adjuster Inside, LH (FOR LH SEAT) |
| 71877E | Cover, Seat Armrest Hole, LH |
| 71910A | Headrest Assy, Front Seat |
| 71931 | Support, Front Seat Headrest |
| 71935 | Clip |
| 71A48 | Clip, Front Seat Leg Cover, LH |
| 71A49D | Cover, Front Seat Leg, Inner NO.1(FOR LH SEAT) |
| 71A49F | Cover, Front Seat Leg, Inner NO.2(FOR LH SEAT) |
| 72010 | Adjuster Assy, Front Seat, RH |
| 72011G | Hinge Sub-assy, Front Seat, LH |
| 72020 | Adjuster Assy, Front Seat, LH |
| 72094D | Lock Sub-assy, Front Seat Turn, LH |
| 72123A | Cover, Seat Track Bracket, Outer Front RH |
| 72124 | Cover, Seat Track Bracket, Outer Front LH |
| 72127A | Cover, Seat Track Bracket, Inner Front RH |
| 72128A | Cover, Seat Track Bracket, Inner Front LH |
| 72129 | Protector, Seat Track Lower Rail, NO.1 |
| 72129A | Protector, Seat Track Lower Rail, NO.2 |
| 72129C | Protector, Seat Track Lower Rail, NO.3 |
| 72129D | Protector, Seat Track Lower Rail, NO.4 |
| 72137J | Cover, Front Seat Track, RH Rear Outer |
| 72138J | Cover, Front Seat Track, LH Rear Outer |
| 72147 | Bracket, Front Inner Seat Track, Lower Rear RH |
| 72148 | Bracket, Front Inner Seat Track, Lower Rear LH |
| 72201B | Handle Sub-assy, Seat Track LH |
| 72211 | Handle, Seat Track Adjusting |
| 72250H | Lock Assy, Front Seat, LH |
| 72265D | Cover, Seat Track Upper Rail |
| 72379 | Belt, Seat Reclining Handle |
| 72404C | Link Sub-assy, Front Seat Adjuster, LH NO.1 |
| 72404E | Link Sub-assy, Front Seat Adjuster, LH NO.2 |
| 72431A | Bracket, Front Seat Adjuster, Front Outer |
| 72432A | Bracket, Front Seat Adjuster, Front Inner |
| 72478C | Bush, Vertical Adjuster, LH |
| 72494 | Handle, Vertical Adjusting, RH |
| 72525A | Handle, Reclining Adjuster Release, RH |
| 72526 | Handle, Reclining Adjuster Release, LH |
| 72526A | Handle, Reclining Adjuster Release, LH |
| 72551 | Cover, Reclining Hinge, NO.1 |
| 72877 | Cover, Seat Armrest, RH |
| 72880 | Armrest Assy, Seat, C RH |
| 72880A | Armrest Assy, Front Seat, Inner RH |
| 72890 | Armrest Assy, Seat, C LH |
| 72939A | Hook, Seat Turn Lock, LH |
| 73162C | Bracket, Belt Anchor Bar, Rear LH |
| 73847B | Cushion, Seat Suspension Stopper, LH |
| 73910A | Airbag Assy, Front Seat, RH |
| 73920A | Airbag Assy, Front Seat, LH |
| 74611H | Grip, Assist |
| 74617D | Plug, Assist Grip |
| 74656P | Cover, Hand Rail Bar, LH |
| 74865G | Cover, Center Protector, LH |
| 76681B | Cover, Outside Moulding End, NO.1 LH |
| 79408F | Hook Sub-assy, NO.4 Seat, Inner LH |
| 79408G | Hook Sub-assy, NO.4 Seat, Outer LH |
| 79968B | Clip |
| 79977A | Felt, Seatback |
| 79977B | Felt, Seatback Frame |
| 82711F | Clamp, Wiring Harness |
| 82H17A | Protector, Wiring Harness, LH |
| 87510K | Heater Assy, Front Seat Cushion, RH |
| 87510L | Heater Assy, Front Seat Cushion, LH |
| 87510M | Heater Assy, Front Seatback, RH |
| 87510N | Heater Assy, Front Seatback, LH |
| C3381 | Cover, Slide Step, NO.1 |
| C3382 | Cover, Slide Step, NO.2 |
| C7015 | Panel Sub-assy, Turn Table |
| C7015C | Panel Sub-assy, Turn Table, LH |
| C7027 | Lock Sub-assy, Welcab Seat Turn |
| C7027E | Lock Sub-assy, Welcab Seat Turn, LH |
| C7032 | Swivel Sub-assy, Front Seat, LH |
| C7104 | Plate Sub-assy, Seat Turn |
| C7106A | Roller Sub-assy, Slide Table, LH |
| C7120 | Leg, Welcab Seat, NO.1 |
| C7139 | Bracket, Hook |
| C7158 | Cover, Welcab Seat Leg |
| C7159 | Cushion, Welcab Seat Leg Stopper |
| C7160 | Panel Assy, Slide Table |
| C7160E | Panel Assy, Slide Table, LH |
| C7169 | Gear, Slide Table Rack |
| C7207A | Bracket Sub-assy, Interlock, Lower LH NO.1 |
| C7210 | Footrest Assy, Welcab Seat |
| C7227 | Carpet, Welcab Seat Footrest Step |
| C7260 | Handle Assy, Seat Turn Lock |
| C7263 | Plate, Welcab Seat Turn Lock, NO.1 |
| C7265A | Handle, Seat Turn Lock, LH |
| C7269 | Cable, Seat Turn Lock Release |
| C7269F | Cable, Seat Turn Lock Release, LH NO.1 |
| C7269H | Cable, Seat Turn Lock Release, LH NO.2 |
| C7275 | Plate, Lock Striker, NO.1 |
| C7276 | Plate, Lock Striker, NO.2 |
| C7881 | Grip, Control Link |
| C7985D | Guard, Rear Seat Turn, LH |
| C7996 | Spacer, Turn Seat, NO.1 |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
