Toyota Corolla

1983-05 → 1987-04 · chassis AE8#,CE80,EE80 · catalogue 151110 · Japan

Discontinued model Data version 1987-11

Manifold

42 part groups · 5 illustrations

PNC	Description
16265	Hose, Intake Manifold Water
16265A	Clamp OR Clip, Hose(FOR INTAKE MANIFOLD WATER)
17110A	Union, Vacuum Hose
17110B	Union(FOR VENTILATION HOSE TO MANIFOLD)
17111	Manifold, Intake
17111A	Plug, NO.1
17111B	Plug, NO.2
17111W	Pin, Slotted Spring(FOR INTAKE MANIFOLD)
17113	Pipe, Intake
17118	Stay, Manifold
17119	Stay, Manifold, NO.2
17129	Tank, Intake Air Surge
17129A	Union, NO.1
17129B	Plug
17129D	Union, NO.2
17129H	Union, NO.4
17129J	Plug, Tight(FOR INTAKE AIR SURGE TANK)
17141	Manifold, Exhaust
17141C	Plug, W/Head Straight Screw
17141D	Bolt, Stud(FOR OXYGEN SENSOR)
17148B	Gasket, Egr Inlet
17151	Bolt, Stud(FOR MANIFOLD TO CARBURETOR)
17151D	Bolt, Stud(MANIFOLD TO THROTTLE BODY)
17152	Bolt, Stud(FOR MANIFOLD TO EXHAUST PIPE)
17159	Bolt, Stud(FOR MANIFOLD TO CYLINDER HEAD)
17167	Insulator, Exhaust Manifold Heat, NO.1
17168	Insulator, Exhaust Manifold Heat, NO.2
17172	Gasket, Manifold TO Cylinder Head
17173	Gasket, Exhaust Manifold TO Head
17176	Gasket, Air Surge Tank TO Intake Manifold
17177	Gasket, Intake Manifold TO Head, NO.1
17179A	Gasket, Intake Manifold, NO.2
17233A	Spring, Spiral, NO.1(FOR COUNTER WEIGHT)
17233B	Spring, Spiral, NO.2(FOR COUNTER WEIGHT)
17233C	Bolt(FOR COUNTER WEIGHT)
17233D	Shim(FOR COUNTER WEIGHT)
17233E	Ring, E(FOR COUNTER WEIGHT)
17300	Valve Assy, Intake Air Control
25508	Converter Sub-assy, Manifold
25508A	Bolt, Stud(FOR MANIFOLD CONVERTER)
25509	Insulator Sub-assy, Manifold Convertor
25576	Gasket, Manifold Converter

PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
