Toyota Sprinter
1991-06 → 2002-06 · chassis AE10#,CE10#,EE10# · catalogue 152130 · Japan
Discontinued model
Data version 2003-01
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 88901 — Motor Sub-assy, Air Purifier | ||||
| 88901-12050 |
Motor Sub-assy, Air Purifier
1991-06 → 1995-05
ended
|
AE10#,CE100,104,EE101 | ¥21,700 | |
| 88912 — Fan, Air Purifier | ||||
| 88912-12050 |
Fan, Air Purifier
1991-06 → 1995-05
ended
|
AE10#,CE100,104,EE101 | ¥1,530 | |
| 88920A — Purifier Assy, Air | ||||
| 88920-12050 |
Purifier Assy, Air
1991-06 → 1995-05
ended
|
AE100,CE100,EE101 DX | — | |
| 88920-12050 note |
Purifier Assy, Air
1991-06 → 1995-05
ended
|
AE10#,CE100,104,EE101 GT,LX,SEG,SEL,XE | — | |
| 88920-12060 note |
Purifier Assy, Air
1991-06 → 1995-05
ended
|
AE10#,CE100,104,EE101 GT,LX,SEG,SEL,XE | — | |
| 88926 — Filter, Air Purifier | ||||
| 88926-12050 |
Filter, Air Purifier
1991-06 → 1995-05
ended
|
AE10#,CE100,104,EE101 | ¥4,700 | |
| 88928A — Case, Air Purifier Filter | ||||
| 88928-12050 |
Case, Air Purifier Filter
1991-06 → 1995-05
ended
|
AE10#,CE100,104,EE101 | ¥3,650 | |
| 88931 — Sensor, Smoke | ||||
| 88931-24030 |
Sensor, Smoke
1991-06 → 1995-05
ended
|
AE10#,CE100,104,EE101 GT,LX,SEG,SEL,XE | ¥12,600 | |
| 88950 — Amplifier Assy, Air Purifier | ||||
| 88950-12050 |
Amplifier Assy, Air Purifier
1991-06 → 1995-05
ended
|
AE100,CE100,EE101 DX | ¥9,300 | |
| 88950-12050 note |
Amplifier Assy, Air Purifier
1991-06 → 1995-05
ended
|
AE10#,CE100,104,EE101 GT,LX,SEG,SEL,XE | ¥9,300 | |
| 88950-12060 note |
Amplifier Assy, Air Purifier
1991-06 → 1995-05
ended
|
AE10#,CE100,104,EE101 GT,LX,SEG,SEL,XE | ¥18,200 | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
