Toyota Corolla Spacio
1997-01 → 2001-05 · chassis AE11# · catalogue 154140 · Japan
Discontinued model
Data version 2002-01
Deck Board & Deck Trim Cover
32 part groups · 2 illustrations
Part groups
| PNC | Description |
|---|---|
| 58410B | Board Assy, Deck |
| 58416F | Bracket, Deck Board, NO.1 |
| 58460D | Striker Assy, Luggage Hold Belt |
| 58556D | Silencer, Rear Floor |
| 58911B | Panel, Box, NO.1 |
| 59315 | Cover, Rear Floor Box |
| 63434 | Net, Room Rack |
| 64429B | Box, Luggage Room |
| 64439B | Cover, Luggage Room Box Side, RH |
| 64449B | Cover, Luggage Room Box Side, LH |
| 64714C | Cover, Deck Side Trim, RH |
| 64715C | Cover, Deck Side Trim, LH |
| 64716D | Cover, Deck Trim, Rear |
| 64716E | Clip(FOR DECK TRIM REAR COVER) |
| 64730B | Panel Assy, Deck Trim Side, RH |
| 64735 | Cover, Deck Trim Side Service Hole |
| 64740C | Panel Assy, Deck Trim Side, LH |
| 64741B | Box, Deck Side Trim, RH |
| 64742C | Box, Deck Side Trim, LH |
| 64746 | Cover, Rear Combination Lamp Service, LH |
| 64750F | Clip(FOR DECK SIDE TRIM PANEL) |
| 64766 | Cover Sub-assy, Quarter Trim Jack |
| 64910J | Cover Assy, Tonneau |
| 64926A | Hook, Tonneau |
| 64935 | Holder, Tonneau Cover, RH |
| 64936 | Holder, Tonneau Cover, LH |
| 64957 | Retainer, Tonneau Cover, RH |
| 64958 | Retainer, Tonneau Cover, LH |
| 67841D | Cover, Quarter Service Hole, RH |
| 67842D | Cover, Quarter Service Hole, LH |
| 73297E | Cover, Deck Trim Side Belt Hole, RH |
| 73298D | Cover,Deck Trim Side Belt Hole, LH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
