Toyota Corolla Spacio
1997-01 → 2001-05 · chassis AE11# · catalogue 154140 · Japan
Discontinued model
Data version 2002-01
Meter
14 part groups · 3 illustrations
Part groups
| PNC | Description |
|---|---|
| 83100B | Bulb, Combination Meter, NO.1 |
| 83132 | Case, Combination Meter |
| 83132A | Case, Meter |
| 83138G | Glass, Combination Meter |
| 83179A | Cover, Meter |
| 83181A | Sensor, Speedometer |
| 83181B | Ring, O (FOR SPEEDOMETER SENSOR) |
| 83189 | Bracket, Meter |
| 83247 | Plate, Meter Circuit |
| 83270 | Tachometer Assy, Engine |
| 83270B | Bulb, Engine Tachometer |
| 83291 | Computer, Combination Meter |
| F1424 | Cell, Computer Meter Liquid Crystal |
| F1911 | Holder, Liquid Crystal Cell |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
