Toyota Corolla Spacio
2001-05 → 2007-06 · chassis NZE121,ZZE12# · catalogue 154150 · Japan
Discontinued model
Data version 2008-01
Rear Seat & Seat Track
102 part groups · 5 illustrations
Part groups
| PNC | Description |
|---|---|
| 66993 | Tray, Rear Center Seat Cup Holder |
| 71015A | Frame Sub-assy, Rear Seat Cushion, RH |
| 71016A | Frame Sub-assy, Rear Seat Cushion, LH |
| 71017A | Frame Sub-assy, Rear Seatback |
| 71018 | Frame Sub-assy, Rear Seatback, LH |
| 71075S | Cover, Rear Seat Cushion, RH (FOR SEPARATE TYPE) |
| 71076S | Cover, Rear Seat Cushion, LH (FOR SEPARATE TYPE) |
| 71077S | Cover, Rear Seatback, RH (FOR SEPARATE TYPE) |
| 71078S | Cover, Rear Seatback, LH(FOR SEPARATE TYPE) |
| 71095S | Cover Sub-assy, Center Seatback |
| 71301D | Hinge Sub-assy, Rear Seat, RH |
| 71302D | Hinge Sub-assy, Rear Seat, LH |
| 71305S | Frame Sub-assy, Center Seatback |
| 71358 | Pad, Center Seatback |
| 71461 | Spring, Rear Seat Cushion |
| 71485A | Cover, Rear Seat Hinge, NO.2 RH |
| 71485C | Cover, Rear Seat Hinge, RH |
| 71485D | Cover, Rear Seat Hinge, LH |
| 71486A | Cover, Rear Seat Hinge, NO.2 LH |
| 71611A | Pad, Rear Seat Cushion, RH |
| 71612A | Pad, Rear Seat Cushion, LH |
| 71629 | Cover, Rear Seat Cushion Hinge |
| 71651S | Pad, Rear Seatback, RH(FOR SEPARATE TYPE) |
| 71652S | Pad, Rear Seatback, LH(FOR SEPARATE TYPE) |
| 71693C | Cover, Rear Seat Cushion Hinge, Outer RH |
| 71693D | Cover, Rear Seat Cushion Hinge, Inner RH |
| 71694D | Cover, Rear Seat Cushion Hinge, Outer LH |
| 71694E | Cover, Rear Seat Cushion Hinge, Inner LH |
| 71695C | Protector, Rear Seat, NO.1 |
| 71696 | Protector, Rear Seat, NO.2 |
| 71726 | Strap, Rear Seat Belt Guide |
| 71778 | Cover, Rear Seat Side Hinge Male, RH |
| 71778B | Cover, Rear Seat Side Hinge Male, RH |
| 71779 | Cover, Rear Seat Side Hinge Male, LH |
| 71880B | Clip(FOR REAR SEATBACK CARPET) |
| 71880C | Carpet Assy, Rear Seatback Board |
| 71931B | Support Assy, Rear NO.1 Seat Headrest |
| 71931C | Support Assy, Rear NO.2 Seat Headrest |
| 71931E | Support Assy, Rear NO.3 Seat Headrest |
| 71940A | Headrest Assy, Rear Seat |
| 71970 | Headrest Assy, Rear Seat |
| 72030 | Adjuster Assy, Rear NO.1 Seat |
| 72040 | Adjuster Assy, Rear NO.2 Seat |
| 72125E | Cover, Seat Track, Upper Rear RH |
| 72125F | Cover, Seat Track, Upper Rear LH |
| 72160 | Track Assy, Rear Seat, Outer RH |
| 72170 | Track Assy, Rear Seat, Outer LH |
| 72180C | Track Assy, Rear Seat, Inner RH |
| 72190 | Track Assy, Rear Seat Inner, LH |
| 72213G | Knob, Seat Track Adjusting Handle, RH |
| 72213H | Knob, Seat Track Adjusting Handle, LH |
| 72241C | Lever, Outer Seat Track Lock, RH |
| 72242A | Lever, Outer Seat Track Lock, LH |
| 72302C | Wire Sub-assy, Rear Seat Track Equalizing, RH |
| 72302D | Wire Sub-assy, Rear Seat Track Equalizing, LH |
| 72345H | Cap, Seat Stand Frame |
| 72348C | Bracket, Seat Stand Spring Set |
| 72510G | Adjuster Assy, Rear Reclining Seat, Outer RH |
| 72520G | Adjuster Assy, Rear Reclining Seat, Outer LH |
| 72550B | Adjuster Assy, Reclining Seat, Center RH |
| 72611B | Clip(FOR REAR SEAT LOCK BASE) |
| 72615A | Cover, Rear Seatback Lock Striker, RH |
| 72615B | Cover, Rear Seat Lock Striker, RH |
| 72616A | Cover, Rear Seatback Lock Striker, LH |
| 72635B | Hook, Rear Seatback Lock(MALE) |
| 72635C | Hook, Rear Seatback Lock(FEMALE) |
| 72637A | Handle, Rear Seat Lock |
| 72655B | Pin, Rear Seatback Rod |
| 72690 | Lever Assy, Seat Cushion Lock Release |
| 72727B | Knob, Rear Seat Reclining Control Lever, RH |
| 72727C | Knob, Rear Seat Reclining Control Lever, LH |
| 72744 | Pin, Rear Seat Reclining Pawl Lock |
| 72745 | Pin, Rear Seat Reclining Hinge |
| 72901 | Frame Sub-assy, 3RD Seat Cushion |
| 72902 | Cover Sub-assy, 3RD Seat Cushion |
| 72903 | Frame Sub-assy, 3RD Seatback |
| 72904 | Cover Sub-assy, 3RD Seatback |
| 72905 | Link Sub-assy, 3RD Seat, RH |
| 72919A | Stopper, 3RD Seat Cushion |
| 72927 | Cover, Rear Seat Cushion Under, RH |
| 72927B | Cover, Rear Seat Cushion Under |
| 72928 | Cover, Rear Seat Cushion Under, LH |
| 72928A | Cover, Rear Seat Cushion Under, NO.2 |
| 72945A | Carpet, 3RD Seat Leg |
| 72953 | Link, 3RD Seat, Lower |
| 72967 | Leg, 3RD Seat |
| 72969A | Pin, Seat Turn Lock Guide |
| 72971 | Plate, Rear Seat Turn Side, RH |
| 72972 | Plate, Rear Seat Turn Side, LH |
| 72995 | Cover, Rear Seat Cushion, RH |
| 72998 | Cover, Rear Seat Cushion, LH |
| 74620E | Strap Assy, Assist, RH |
| 74620F | Strap Assy, Assist, LH |
| 79021 | Cover Sub-assy, NO.2 Seat Cushion, RH |
| 79022 | Cover Sub-assy, NO.2 Seat Cushion, LH |
| 79101B | Frame Sub-assy, NO.1 Seat Cushion, RH |
| 79102 | Frame Sub-assy, NO.1 Seat Cushion, LH |
| 79117B | Cover, NO.1 Seat Cushion, RH |
| 79117C | Cover, NO.1 Seat Cushion, LH |
| 79135A | Pad, NO.1 Seat Cushion, RH |
| 79136B | Pad, NO.1 Seat Cushion, LH |
| 79247 | Pad, Junior Seat Cushion Cover, A |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
