Toyota Corolla Rumion

2007-10 → 2015-12 · chassis NZE151,ZRE15# · catalogue 154160 · Japan

Supported model Data version 2016-06
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Back Door Panel & Glass

19 part groups · 2 illustrations

Illustrations

Figure 675406B 675406B 2007-10 → — Figure 675432B 675432B 2007-10 → —

Part groups

PNCDescription
64790B Panel Assy, Back Door Trim, Upper
64818C Spacer, Back Window Glass, NO.1
64819B Spacer, Back Window Glass, NO.2
64885A Channel, Back Window Glass, RH
64886 Channel, Back Window Glass, LH
67005 Panel Sub-assy, Back Door
67005B Cushion(FOR BACK DOOR PANEL)
67750 Board Assy, Back Door Trim
67751A Clip(FOR BACK DOOR TRIM BOARD)
67819 Pad, Back Door Outside Panel
67881A Weatherstrip, Back Door
67893A Protector, Back Door Panel, NO.1
67894B Protector, Back Door Panel, NO.2
68131 Glass, Back Door
68294A Dam, Back Door Glass Adhesive
68294B Dam, Back Door Glass Adhesive
74811D Handle, Door Pull
75129C Cushion, Rear Licence Plate
75573H Moulding, Back Window, Outside
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
