Toyota Corolla Rumion

2007-10 → 2015-12 · chassis NZE151,ZRE15# · catalogue 154160 · Japan

Supported model Data version 2016-06
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Caution Plate (EXTERIOR & INTERIOR)

23 part groups · 2 illustrations

Illustrations

Figure 742399D 742399D 2007-10 → — Figure 742400D 742400D 2007-10 → —

Part groups

PNCDescription
11285A Label, Coolant System Notice
11296C Label, Engine Service Information
41992 Label, Differential Notice
69339C Label, Child Protector Information
74511F Label, Name (IDENTIFICATION LASER LABEL)
74512A Plate, Identification Number
74541 Plate, Tire Pressure Caution
74541E Plate, Compact Spare Tire Caution
74553A Plate, Front Seat Caution
74561A Label, Fuel Consumption Information
74562B Label, Emission Information
74571A Film, Label Cover
74598A Label, Passenger Airbag Caution
87529B Label, A/C Filter Information
88723J Label, Cooler Service Caution, NO.2
89176A Label, Airbag Deployment Information
89616 Label, Push Start Information
C6111 Plate, Safety Caution
C6111A Plate, Safety Caution
C6112 Label, Safety Information, NO.2
C6161 Label, Power Lift Caution
C6162 Label, Power Lift Caution, NO.2
C6248 Label, Body Number
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
