Toyota Voltz
2002-05 → 2004-02 · chassis ZZE13# · catalogue 171150 · Japan
Supported model
Data version 2003-08
Instrument Panel & Glove Compartment
35 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 55054 | Stopper Sub-assy, Glove Compartment Door |
| 55302A | Panel Sub-assy, Instrument, Upper |
| 55303B | Panel Sub-assy, Instrument, Lower |
| 55306A | Brace Sub-assy, Instrument Panel, NO.1 |
| 55307C | Brace Sub-assy, Instrument Panel, NO.2 |
| 55308C | Bracket Sub-assy, Instrument Panel, Center |
| 55312A | Clip, Instrument Panel |
| 55315A | Spacer, Instrument Panel, NO.1 |
| 55331 | Reinforcement, Instrument Panel |
| 55355 | Cushion, Instrument Panel, NO.1 |
| 55368C | Bracket, Meter Mounting |
| 55374C | Bracket, Instrument Panel Lower Mounting, NO.1 |
| 55403 | Hood Sub-assy, Meter |
| 55404C | Panel Sub-assy, Instrument Cluster Finish, NO.2 |
| 55405B | Panel Sub-assy, Instrument Cluster Finish, Center |
| 55411G | Panel, Instrument Cluster Finish, NO.1 |
| 55412C | Panel, Instrument Cluster Finish, Center NO.1 |
| 55413C | Panel, Instrument Cluster Finish, Center NO.2 |
| 55434B | Panel, Instrument Panel Finish, Lower Center |
| 55441 | Box, Instrument Panel |
| 55441C | Box, Instrument Panel Coin |
| 55441E | Box, Instrument Panel |
| 55444A | Spring, Instrument Panel Box |
| 55444C | Spring, Instrument Panel Box |
| 55445C | Plate, Instrument Panel Box |
| 55503B | Cushion(FOR GLOVE COMPARTMENT) |
| 55522B | Cover, Radio Tuner Opening |
| 55539C | Cover, Spare Switch Hole |
| 55550 | Door Assy, Glove Compartment |
| 55560A | Lock Assy, Glove Compartment Door |
| 55650 | Register Assy, Instrument Panel, NO.1 |
| 55650C | Register Assy, Instrument Panel, NO.1 |
| 58971C | Lock, Console Compartment Door |
| 73970A | Airbag Assy, Instrument Panel Passenger |
| 81942C | Sheet, Heater Control Name |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
