Toyota Carina FR

1981-09 → 1988-04 · chassis TA6#,AA6#,SA60,RA63,KA67,CA6# · catalogue 221130 · Japan

Discontinued model Data version 1988-05
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Armrest & Visor

22 part groups · 2 illustrations

Illustrations

Figure MBC845G MBC845G 1981-09 → — Figure MBC846A MBC846A 1981-09 → 1985-07

Part groups

PNCDescription
74210 Armrest Assy, Front, RH
74220 Armrest Assy, Front, LH
74223 Cap, Door Armrest, RH
74224 Cap, Door Armrest, LH
74230 Armrest Assy, Rear, RH
74240 Armrest Assy, Rear, LH
74257 Spring, Armrest, NO.1
74281 Pocket, Door Armrest, RH
74282 Pocket, Door Armrest, LH
74285 Clip, Door Armrest Pocket
74286 Clip, Door Armrest Pocket, NO.2
74310 Visor Assy, RH
74320 Visor Assy, LH
74348 Holder, Visor
74387 Bracket, Rear Visor, NO.1
74388 Bracket, Rear Visor, NO.2
74390 Visor Assy, Rear, Inner
74603 Grip Sub-assy, Assist, Front
74604 Grip Sub-assy, Assist, Rear
74613 Plug, Assist Grip
74810 Pull Assy, Door, Inside
74810C Plug, Door Pull Handle
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
