Toyota Prius
1997-12 → 2003-08 · chassis NHW1# · catalogue 222110 · Japan
Discontinued model
Data version 2004-01
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 52015A — Arm Sub-assy, Rear Bumper, RH | ||||
| 52181-47010 |
Arm Sub-assy, Rear Bumper, RH
1997-12 → —
|
NHW1# | ¥1,810 | |
| 52181-47020 note |
Arm Sub-assy, Rear Bumper, RH
2001-08 → —
|
NHW11 | ¥2,680 | |
| 52016A — Arm Sub-assy, Rear Bumper, LH | ||||
| 52181-47010 |
Arm Sub-assy, Rear Bumper, LH
1997-12 → —
|
NHW1# | ¥1,810 | |
| 52182-47010 note |
Arm Sub-assy, Rear Bumper, LH
2001-08 → —
|
NHW11 | ¥2,680 | |
| 52023 — Reinforcement Sub-assy, Rear Bumper | ||||
| 52171-47010 |
Reinforcement Sub-assy, Rear Bumper
2001-08 → —
|
NHW11 | ¥39,800 | |
| 52116F — Retainer, Rear Bumper | ||||
| 52116-12310 |
Retainer, Rear Bumper
1997-12 → —
|
NHW1# | ¥450 | |
| 52137E — Plate, Rear Bumper Bracket, NO.1 | ||||
| 52137-12090 |
Plate, Rear Bumper Bracket, NO.1
1997-12 → —
|
NHW1# | ¥330 | |
| 52159 — Cover, Rear Bumper | ||||
| 52159-47010-A0 note |
Cover, Rear Bumper
1997-12 → 2000-05
ended
|
NHW10 | ¥49,500 | |
| 52159-47010-A1 note |
Cover, Rear Bumper
1998-11 → 2000-05
ended
|
NHW10 | ¥49,500 | |
| 52159-47010-B0 note |
Cover, Rear Bumper
1999-11 → 2000-05
ended
|
NHW10 | ¥49,500 | |
| 52159-47010-D0 note |
Cover, Rear Bumper
1997-12 → 1999-01
ended
|
NHW10 | ¥49,500 | |
| 52159-47010-G1 note |
Cover, Rear Bumper
1997-12 → 2000-05
ended
|
NHW10 | ¥49,500 | |
| 52159-47010-H0 note |
Cover, Rear Bumper
1997-12 → 2000-05
ended
|
NHW10 | ¥49,500 | |
| 52159-47010-J0 note |
Cover, Rear Bumper
1997-12 → 2000-05
ended
|
NHW10 | ¥49,500 | |
| 52159-47010-K0 note |
Cover, Rear Bumper
1997-12 → 2000-05
ended
|
NHW10 | ¥49,500 | |
| 52159-47020-A0 note |
Cover, Rear Bumper
2000-05 → —
|
NHW11 | ¥44,900 | |
| 52159-47020-A1 note |
Cover, Rear Bumper
2000-05 → —
|
NHW11 | ¥44,900 | |
| 52159-47020-B0 note |
Cover, Rear Bumper
2000-05 → —
|
NHW11 | ¥44,900 | |
| 52159-47020-C0 note |
Cover, Rear Bumper
2001-09 → —
|
NHW11 | ¥44,900 | |
| 52159-47020-D0 note |
Cover, Rear Bumper
2001-08 → —
|
NHW11 | ¥44,900 | |
| 52159-47020-D0 note |
Cover, Rear Bumper
2000-12 → 2001-12
ended
|
NHW11 S | ¥44,900 | |
| 52159-47020-G0 note |
Cover, Rear Bumper
2000-05 → —
|
NHW11 | ¥44,900 | |
| 52159-47020-H0 note |
Cover, Rear Bumper
2000-05 → —
|
NHW11 | ¥44,900 | |
| 52159-47020-J0 note |
Cover, Rear Bumper
2000-05 → —
|
NHW11 | ¥44,900 | |
| 52159-47020-J1 note |
Cover, Rear Bumper
2000-05 → —
|
NHW11 | ¥44,900 | |
| 52161B — Piece, Rear Bumper | ||||
| 52161-16010 |
Piece, Rear Bumper
1997-12 → —
|
NHW1# | ¥120 | |
| 52752 — Moulding, Rear Bumper Side, RH | ||||
| 52752-47010-B0 note |
Moulding, Rear Bumper Side, RH
1997-12 → 1998-11
ended
|
NHW10 | ¥4,920 | |
| 52752-47010-B0 note |
Moulding, Rear Bumper Side, RH
1998-11 → 1999-01
ended
|
NHW10 | ¥4,920 | |
| 52752-47010-B0 note |
Moulding, Rear Bumper Side, RH
1999-01 → 1999-11
ended
|
NHW10 | ¥4,920 | |
| 52752-47010-B0 note |
Moulding, Rear Bumper Side, RH
1999-11 → 2000-05
ended
|
NHW10 | ¥4,920 | |
| 52753 — Moulding, Rear Bumper Side, LH | ||||
| 52753-47010-B0 note |
Moulding, Rear Bumper Side, LH
1997-12 → 1998-11
ended
|
NHW10 | ¥4,920 | |
| 52753-47010-B0 note |
Moulding, Rear Bumper Side, LH
1998-11 → 1999-01
ended
|
NHW10 | ¥4,920 | |
| 52753-47010-B0 note |
Moulding, Rear Bumper Side, LH
1999-01 → 1999-11
ended
|
NHW10 | ¥4,920 | |
| 52753-47010-B0 note |
Moulding, Rear Bumper Side, LH
1999-11 → 2000-05
ended
|
NHW10 | ¥4,920 | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
