Toyota Prius
1997-12 → 2003-08 · chassis NHW1# · catalogue 222110 · Japan
Discontinued model
Data version 2004-01
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 81570 — Lamp Assy, Center Stop | ||||
| 81570-47010 |
Lamp Assy, Center Stop
1997-12 → 2002-08
ended
|
NHW1# | ¥11,100 | |
| 81570-47030 note |
Lamp Assy, Center Stop
2002-01 → 2002-12
ended
|
NHW11 S | ¥13,400 | |
| 81570-47030 note |
Lamp Assy, Center Stop
2000-05 → —
|
NHW11 | ¥13,400 | |
| 81570B — Bulb (FOR CENTER STOP LAMP) | ||||
| 99132-12050 note |
Bulb (FOR CENTER STOP LAMP)
1997-12 → 2002-08
ended
|
NHW1# | ¥110 | |
| 99132-12050 note |
Bulb (FOR CENTER STOP LAMP)
2000-05 → —
|
NHW11 | ¥110 | |
| 81977 — Cover, Center Stop Lamp | ||||
| 81977-47010-B0 note |
Cover, Center Stop Lamp
1997-12 → 1998-11
ended
|
NHW10 | ¥3,420 | |
| 81977-47010-B0 note |
Cover, Center Stop Lamp
1998-11 → 2000-05
ended
|
NHW10 | ¥3,420 | |
| 81977-47010-B1 note |
Cover, Center Stop Lamp
2000-05 → 2002-08
ended
|
NHW11 | ¥3,440 | |
| 81977-47020-B1 note |
Cover, Center Stop Lamp
2002-01 → 2002-12
ended
|
NHW11 S | ¥3,460 | |
| 81977-47020-B1 note |
Cover, Center Stop Lamp
2000-05 → —
|
NHW11 | ¥3,460 | |
| 81977-47020-B1 note |
Cover, Center Stop Lamp
2002-08 → —
|
NHW11 | ¥3,460 | |
| 81977A — Clip (FOR CENTER STOP LAMP) | ||||
| 90467-05022-B2 note |
Clip (FOR CENTER STOP LAMP)
2000-05 → —
|
NHW11 | ¥270 | |
| 90467-05022-B3 note |
Clip (FOR CENTER STOP LAMP)
1997-12 → 1998-11
ended
|
NHW10 | ¥270 | |
| 90467-05022-B3 note |
Clip (FOR CENTER STOP LAMP)
1998-11 → 2000-05
ended
|
NHW10 | ¥270 | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
