Toyota Prius
2003-08 → 2011-12 · chassis NHW20 · catalogue 222120 · Japan
Supported model
Data version 2012-01
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 16100 — Pump Assy, Engine Water | ||||
| 16100-29155 |
Pump Assy, Engine Water
2003-08 → 2005-06
ended
|
1NZFXE NHW20 | ¥10,700 | |
| 16100-29156 |
Pump Assy, Engine Water
2005-06 → 2005-11
ended
|
1NZFXE NHW20 | ¥9,300 | |
| 16100-29156 |
Pump Assy, Engine Water
2005-11 → 2011-11
ended
|
1NZFXE NHW20 | ¥9,300 | |
| 16100-29157 |
Pump Assy, Engine Water
2011-11 → 2011-12
ended
|
1NZFXE NHW20 | ¥8,400 | |
| 16173 — Pulley, Water Pump | ||||
| 16173-21020 |
Pulley, Water Pump
2003-08 → 2005-11
ended
|
1NZFXE NHW20 | ¥2,970 | |
| 16173-21020 |
Pulley, Water Pump
2005-11 → 2009-03
ended
|
1NZFXE NHW20 G | ¥2,970 | |
| 16173-21020 |
Pulley, Water Pump
2005-11 → —
|
1NZFXE NHW20 S | ¥2,970 | |
| 16271 — Gasket, Water Pump | ||||
| 16271-21020 |
Gasket, Water Pump
2003-08 → 2005-11
ended
|
1NZFXE NHW20 | ¥620 | |
| 16271-21020 |
Gasket, Water Pump
2005-11 → 2011-11
ended
|
1NZFXE NHW20 | ¥620 | |
| 16271-21021 |
Gasket, Water Pump
2011-11 → 2011-12
ended
|
1NZFXE NHW20 | ¥380 | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
