Toyota Prius
2003-08 → 2011-12 · chassis NHW20 · catalogue 222120 · Japan
Supported model
Data version 2012-01
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 22030 — Body Assy, Throttle W/Throttle Position Sensor | ||||
| 22030-21020 |
Body Assy, Throttle W/Throttle Position Sensor
2003-08 → 2005-11
ended
|
1NZFXE NHW20 | ¥83,600 | |
| 22030-21020 |
Body Assy, Throttle W/Throttle Position Sensor
2005-11 → 2009-03
ended
|
1NZFXE NHW20 G | ¥83,600 | |
| 22030-21020 |
Body Assy, Throttle W/Throttle Position Sensor
2005-11 → —
|
1NZFXE NHW20 S | ¥83,600 | |
| 22271 — Gasket, Throttle Body | ||||
| 22271-21030 |
Gasket, Throttle Body
2003-08 → 2005-11
ended
|
1NZFXE NHW20 | ¥430 | |
| 22271-21030 |
Gasket, Throttle Body
2005-11 → 2009-03
ended
|
1NZFXE NHW20 G | ¥430 | |
| 22271-21030 |
Gasket, Throttle Body
2005-11 → —
|
1NZFXE NHW20 S | ¥430 | |
| 23250 — Injector Assy, Fuel | ||||
| 23209-21020 |
Injector Assy, Fuel
2003-08 → 2005-11
ended
|
1NZFXE NHW20 | ¥20,100 | |
| 23209-21020 |
Injector Assy, Fuel
2005-11 → 2011-12
ended
|
1NZFXE NHW20 | ¥20,100 | |
| 23250B — Ring, O(FOR FUEL INJECTOR) | ||||
| 90301-07024 |
Ring, O(FOR FUEL INJECTOR)
2003-08 → 2005-11
ended
|
1NZFXE NHW20 | ¥190 | |
| 90301-07024 |
Ring, O(FOR FUEL INJECTOR)
2005-11 → 2006-07
ended
|
1NZFXE NHW20 | ¥190 | |
| 90301-07037 |
Ring, O(FOR FUEL INJECTOR)
2006-07 → 2009-03
ended
|
1NZFXE NHW20 G | ¥140 | |
| 90301-07037 |
Ring, O(FOR FUEL INJECTOR)
2006-07 → —
|
1NZFXE NHW20 S | ¥140 | |
| 23291 — Insulator, Injector Vibration | ||||
| 23291-41010 |
Insulator, Injector Vibration
2003-08 → 2005-11
ended
|
1NZFXE NHW20 | ¥340 | |
| 23291-23010 |
Insulator, Injector Vibration
2011-07 → —
|
1NZFXE NHW20 | ¥240 | |
| 23291-41010 |
Insulator, Injector Vibration
2005-11 → 2011-07
ended
|
1NZFXE NHW20 | ¥340 | |
| 23807 — Pipe Sub-assy, Fuel Delivery | ||||
| 23814-21070 note |
Pipe Sub-assy, Fuel Delivery
2003-08 → 2005-01
ended
|
1NZFXE NHW20 | ¥13,200 | |
| 23814-21071 note |
Pipe Sub-assy, Fuel Delivery
2005-01 → 2005-11
ended
|
1NZFXE NHW20 | ¥13,200 | |
| 23814-21071 |
Pipe Sub-assy, Fuel Delivery
2005-11 → 2006-12
ended
|
1NZFXE NHW20 | ¥13,200 | |
| 23814-21072 |
Pipe Sub-assy, Fuel Delivery
2006-12 → 2011-12
ended
|
1NZFXE NHW20 | ¥13,000 | |
| 23807V — Spacer, NO.1(FOR DELIVERY PIPE) | ||||
| 23891-21010 |
Spacer, NO.1(FOR DELIVERY PIPE)
2003-08 → 2005-11
ended
|
1NZFXE NHW20 | ¥240 | |
| 23891-21010 |
Spacer, NO.1(FOR DELIVERY PIPE)
2005-11 → 2009-03
ended
|
1NZFXE NHW20 G | ¥240 | |
| 23891-21010 |
Spacer, NO.1(FOR DELIVERY PIPE)
2005-11 → —
|
1NZFXE NHW20 S | ¥240 | |
| 23841B — Clamp, Fuel Pipe, NO.1(FOR EFI) | ||||
| 23841-28010 |
Clamp, Fuel Pipe, NO.1(FOR EFI)
2003-08 → 2005-11
ended
|
1NZFXE NHW20 | ¥370 | |
| 23841-21050 |
Clamp, Fuel Pipe, NO.1(FOR EFI)
2006-07 → 2009-03
ended
|
1NZFXE NHW20 G | ¥220 | |
| 23841-21050 |
Clamp, Fuel Pipe, NO.1(FOR EFI)
2006-07 → —
|
1NZFXE NHW20 S | ¥220 | |
| 23841-28010 |
Clamp, Fuel Pipe, NO.1(FOR EFI)
2005-11 → 2006-06
ended
|
1NZFXE NHW20 | ¥370 | |
| 23901 — Tube Sub-assy, Fuel | ||||
| 23901-21080 note |
Tube Sub-assy, Fuel
2003-08 → 2005-01
ended
|
1NZFXE NHW20 | ¥5,900 | |
| 23901-21081 note |
Tube Sub-assy, Fuel
2005-01 → 2005-11
ended
|
1NZFXE NHW20 | ¥5,900 | |
| 23901-21081 |
Tube Sub-assy, Fuel
2005-11 → 2011-12
ended
|
1NZFXE NHW20 | ¥5,900 | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
