Toyota Prius
2003-08 → 2011-12 · chassis NHW20 · catalogue 222120 · Japan
Supported model
Data version 2012-01
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 51201 — Crossmember Sub-assy, Front Suspension | ||||
| 51201-47030 |
Crossmember Sub-assy, Front Suspension
2003-08 → 2005-11
ended
|
NHW20 | ¥66,500 | |
| 51201-47030 |
Crossmember Sub-assy, Front Suspension
2005-11 → 2011-12
ended
|
NHW20 | ¥66,500 | |
| 51441C — Cover, Engine Under, RH | ||||
| 51408-47010 |
Cover, Engine Under, RH
2003-08 → 2005-11
ended
|
NHW20 | ¥10,200 | |
| 51408-47011 |
Cover, Engine Under, RH
2005-11 → 2005-12
ended
|
NHW20 | ¥10,200 | |
| 51408-47012 |
Cover, Engine Under, RH
2006-01 → —
|
NHW20 | ¥9,900 | |
| 51442C — Cover, Engine Under, LH | ||||
| 51409-47010 |
Cover, Engine Under, LH
2003-08 → 2005-11
ended
|
NHW20 | ¥10,200 | |
| 51409-47011 |
Cover, Engine Under, LH
2005-11 → 2005-12
ended
|
NHW20 | ¥10,200 | |
| 51409-47012 |
Cover, Engine Under, LH
2006-01 → —
|
NHW20 | ¥9,900 | |
| 51451D — Screw, NO.1 | ||||
| 90159-60215 |
Screw, NO.1
2003-08 → 2005-11
ended
|
NHW20 | ¥70 | |
| 90159-60215 |
Screw, NO.1
2005-11 → 2011-12
ended
|
NHW20 | ¥70 | |
| 51454 — Clip | ||||
| 90467-05114 |
Clip
2003-08 → 2005-11
ended
|
NHW20 | ¥200 | |
| 90467-05114 |
Clip
2005-11 → 2011-12
ended
|
NHW20 | ¥200 | |
| 51967B — Hook, Transport, Rear RH | ||||
| 51967-10100 |
Hook, Transport, Rear RH
2003-08 → 2005-11
ended
|
NHW20 | ¥2,650 | |
| 51967-10100 |
Hook, Transport, Rear RH
2005-11 → —
|
NHW20 | ¥2,650 | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
