Toyota Prius
2003-08 → 2011-12 · chassis NHW20 · catalogue 222120 · Japan
Supported model
Data version 2012-01
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 74414B — Reinforcement, Battery Bracket | ||||
| 74409-47020 |
Reinforcement, Battery Bracket
2003-08 → 2005-11
ended
|
NHW20 | ¥1,860 | |
| 74409-47020 |
Reinforcement, Battery Bracket
2005-11 → —
|
NHW20 | ¥1,860 | |
| 74417 — Bracket, Battery Carrier | ||||
| 74417-47020 |
Bracket, Battery Carrier
2003-08 → 2005-11
ended
|
NHW20 | ¥6,700 | |
| 74417-47020 |
Bracket, Battery Carrier
2005-11 → —
|
NHW20 | ¥6,700 | |
| 74431 — Tray, Battery | ||||
| 74440-47010 |
Tray, Battery
2003-08 → 2005-11
ended
|
NHW20 S | ¥1,410 | |
| 74440-47020 |
Tray, Battery
2003-08 → 2005-11
ended
|
NHW20 G | ¥1,470 | |
| 74440-47010 |
Tray, Battery
2005-11 → 2011-12
ended
|
NHW20 S | ¥1,410 | |
| 74440-47020 |
Tray, Battery
2005-11 → 2009-03
ended
|
NHW20 G | ¥1,470 | |
| 74440-47020 note |
Tray, Battery
2007-03 → 2009-03
ended
|
NHW20 S | ¥1,470 | |
| 74481 — Clamp, Battery Hold Down | ||||
| 74480-47010 |
Clamp, Battery Hold Down
2003-08 → 2005-11
ended
|
NHW20 | ¥970 | |
| 74480-47010 |
Clamp, Battery Hold Down
2005-11 → —
|
NHW20 | ¥970 | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
