Toyota Prius
2003-08 → 2011-12 · chassis NHW20 · catalogue 222120 · Japan
Supported model
Data version 2012-01
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 48966 — Bracket, Sensor Connecting, Rear | ||||
| 48966-47010 note |
Bracket, Sensor Connecting, Rear
2003-08 → 2005-11
ended
|
NHW20 | ¥970 | |
| 48966-47010 note |
Bracket, Sensor Connecting, Rear
2003-08 → 2005-11
ended
|
NHW20 | ¥970 | |
| 48966-47010 note |
Bracket, Sensor Connecting, Rear
2005-11 → 2009-03
ended
|
NHW20 | ¥970 | |
| 48966-47010 note |
Bracket, Sensor Connecting, Rear
2005-11 → 2009-04
ended
|
NHW20 | ¥970 | |
| 89408C — Sensor Sub-assy, Height Control, Rear LH | ||||
| 89408-47010 note |
Sensor Sub-assy, Height Control, Rear LH
2003-08 → 2005-11
ended
|
NHW20 | ¥41,700 | |
| 89408-47010 note |
Sensor Sub-assy, Height Control, Rear LH
2003-08 → 2005-11
ended
|
NHW20 | ¥41,700 | |
| 89408-47010 note |
Sensor Sub-assy, Height Control, Rear LH
2005-11 → 2009-03
ended
|
NHW20 | ¥41,700 | |
| 89408-47010 note |
Sensor Sub-assy, Height Control, Rear LH
2005-11 → 2009-04
ended
|
NHW20 | ¥41,700 | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
