Toyota Prius
2003-08 → 2011-12 · chassis NHW20 · catalogue 222120 · Japan
Supported model
Data version 2012-01
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 85110 — Motor Assy, Windshield Wiper | ||||
| 85110-13110 |
Motor Assy, Windshield Wiper
2003-08 → 2005-11
ended
|
NHW20 | ¥27,300 | |
| 85110-47070 note |
Motor Assy, Windshield Wiper
2003-08 → 2005-11
ended
|
NHW20 | ¥30,400 | |
| 85110-13110 |
Motor Assy, Windshield Wiper
2005-11 → —
|
NHW20 | ¥27,300 | |
| 85110-47070 note |
Motor Assy, Windshield Wiper
2005-11 → —
|
NHW20 | ¥30,400 | |
| 85160 — Link Assy, Windshield Wiper | ||||
| 85150-47060 |
Link Assy, Windshield Wiper
2003-08 → 2005-11
ended
|
NHW20 | ¥7,500 | |
| 85150-47080 note |
Link Assy, Windshield Wiper
2003-08 → 2005-11
ended
|
NHW20 | ¥7,500 | |
| 85150-47060 |
Link Assy, Windshield Wiper
2005-11 → —
|
NHW20 | ¥7,500 | |
| 85150-47080 note |
Link Assy, Windshield Wiper
2005-11 → —
|
NHW20 | ¥7,500 | |
| 85178 — Nut (FOR FRONT WIPER ARM SETTING) | ||||
| 90179-10223 |
Nut (FOR FRONT WIPER ARM SETTING)
2003-08 → 2005-11
ended
|
NHW20 | ¥100 | |
| 90179-10223 |
Nut (FOR FRONT WIPER ARM SETTING)
2005-11 → —
|
NHW20 | ¥100 | |
| 85192 — Cover, Windshield Wiper Arm | ||||
| 85292-13010 |
Cover, Windshield Wiper Arm
2003-08 → 2005-11
ended
|
NHW20 | ¥250 | |
| 85292-13010 |
Cover, Windshield Wiper Arm
2005-11 → —
|
NHW20 | ¥250 | |
| 85211B — Arm, Front Wiper, RH | ||||
| 85211-47040 |
Arm, Front Wiper, RH
2003-08 → 2005-11
ended
|
NHW20 | ¥4,860 | |
| 85211-47040 |
Arm, Front Wiper, RH
2005-11 → —
|
NHW20 | ¥4,860 | |
| 85212A — Blade, FR Wiper, RH | ||||
| 85212-68010 |
Blade, FR Wiper, RH
2003-08 → 2005-11
ended
|
NHW20 | ¥4,290 | |
| 85212-68010 |
Blade, FR Wiper, RH
2005-11 → —
|
NHW20 | ¥4,290 | |
| 85214A — Rubber, Wiper, RH | ||||
| 85214-44140 |
Rubber, Wiper, RH
2003-08 → 2005-11
ended
|
NHW20 | ¥900 | |
| 85214-44140 |
Rubber, Wiper, RH
2005-11 → —
|
NHW20 | ¥900 | |
| 85214B — Rubber, Wiper, LH | ||||
| 85214-50060 |
Rubber, Wiper, LH
2003-08 → 2005-11
ended
|
NHW20 | ¥830 | |
| 85214-50060 |
Rubber, Wiper, LH
2005-11 → 2006-07
ended
|
NHW20 | ¥830 | |
| 85214-50061 |
Rubber, Wiper, LH
2006-08 → —
|
NHW20 | ¥650 | |
| 85221B — Arm, Front Wiper, LH | ||||
| 85221-47030 |
Arm, Front Wiper, LH
2003-08 → 2005-11
ended
|
NHW20 | ¥5,800 | |
| 85221-47030 |
Arm, Front Wiper, LH
2005-11 → —
|
NHW20 | ¥5,800 | |
| 85222A — Blade, FR Wiper, LH | ||||
| 85222-13040 |
Blade, FR Wiper, LH
2003-08 → 2005-11
ended
|
NHW20 | ¥2,090 | |
| 85222-13040 |
Blade, FR Wiper, LH
2005-11 → 2006-07
ended
|
NHW20 | ¥2,090 | |
| 85222-13041 |
Blade, FR Wiper, LH
2006-08 → —
|
NHW20 | ¥1,640 | |
| 85291A — Blade, Front Wiper, Winter, RH | ||||
| 85291-44070 note |
Blade, Front Wiper, Winter, RH
2003-08 → 2005-11
ended
|
NHW20 | ¥6,600 | |
| 85291-44070 note |
Blade, Front Wiper, Winter, RH
2003-08 → 2005-11
ended
|
NHW20 | ¥6,600 | |
| 85291-44090 note |
Blade, Front Wiper, Winter, RH
2003-08 → 2005-11
ended
|
NHW20 | ¥8,000 | |
| 85291-44090 note |
Blade, Front Wiper, Winter, RH
2003-08 → 2005-11
ended
|
NHW20 | ¥8,000 | |
| 85291-44070 note |
Blade, Front Wiper, Winter, RH
2005-11 → 2009-03
ended
|
NHW20 S | ¥6,600 | |
| 85291-44070 note |
Blade, Front Wiper, Winter, RH
2005-11 → —
|
NHW20 | ¥6,600 | |
| 85291-44090 note |
Blade, Front Wiper, Winter, RH
2005-11 → 2009-03
ended
|
NHW20 S | ¥8,000 | |
| 85291-44090 note |
Blade, Front Wiper, Winter, RH
2005-11 → —
|
NHW20 | ¥8,000 | |
| 85291B — Blade, Front Wiper, Winter, LH | ||||
| 85291-44080 note |
Blade, Front Wiper, Winter, LH
2003-08 → 2005-11
ended
|
NHW20 | ¥3,600 | |
| 85291-44080 note |
Blade, Front Wiper, Winter, LH
2003-08 → 2005-11
ended
|
NHW20 | ¥3,600 | |
| 85291-44080 note |
Blade, Front Wiper, Winter, LH
2005-11 → 2009-03
ended
|
NHW20 S | ¥3,600 | |
| 85291-44080 note |
Blade, Front Wiper, Winter, LH
2005-11 → —
|
NHW20 | ¥3,600 | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
