Toyota Prius
2015-11 → 2022-11 · chassis ZVW5# · catalogue 222140 · Japan
Supported model
Data version 2023-11
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 86160 — Speaker Assy, Front NO.1 | ||||
| 86150-47010 note |
Speaker Assy, Front NO.1
2018-02 → 2018-12
ended
|
ZVW51,55 (A,PREM) CBU | ¥22,100 | |
| 86160-0WX80 note |
Speaker Assy, Front NO.1
2017-11 → 2018-01
ended
|
ZVW51,55 (A,PREM) CBU | ¥26,500 | |
| 86160-28820 |
Speaker Assy, Front NO.1
2015-11 → 2018-12
ended
|
ZVW5# CBU | ¥7,000 | |
| 86150-47010 note |
Speaker Assy, Front NO.1
2018-12 → 2021-06
ended
|
ZVW5# PREM | ¥22,100 | |
| 86160-28820 |
Speaker Assy, Front NO.1
2018-12 → —
|
ZVW5# CBU | ¥7,000 | |
| 86160B — Speaker Assy, Rear | ||||
| 86160-0R140 note |
Speaker Assy, Rear
2017-11 → 2018-01
ended
|
ZVW51,55 (A,PREM) CBU | ¥33,900 | |
| 86160-28820 |
Speaker Assy, Rear
2015-11 → 2018-12
ended
|
ZVW5# (A,PREM,S) CBU | ¥7,000 | |
| 86160-47270 note |
Speaker Assy, Rear
2018-02 → 2018-12
ended
|
ZVW51,55 (A,PREM) CBU | ¥28,200 | |
| 86160-28820 |
Speaker Assy, Rear
2018-12 → —
|
ZVW5# (A,PREM,S) CBU | ¥7,000 | |
| 86160-47270 note |
Speaker Assy, Rear
2018-12 → 2021-06
ended
|
ZVW5# PREM | ¥28,200 | |
| 86160P — Speaker Assy, Front NO.2 | ||||
| 86160-0WU50 note |
Speaker Assy, Front NO.2
2017-11 → 2018-01
ended
|
ZVW51,55 (A,PREM) CBU | ¥15,300 | |
| 86160-33840 note |
Speaker Assy, Front NO.2
2018-02 → 2018-12
ended
|
ZVW51,55 (A,PREM) CBU | ¥12,700 | |
| 86160-47140 |
Speaker Assy, Front NO.2
2015-11 → 2018-12
ended
|
ZVW5# CBU | ¥5,800 | |
| 86160-33840 note |
Speaker Assy, Front NO.2
2018-12 → 2021-06
ended
|
ZVW5# PREM | ¥12,700 | |
| 86160-47140 |
Speaker Assy, Front NO.2
2018-12 → —
|
ZVW5# CBU | ¥5,800 | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
