Toyota Carina FF

1988-05 → 1992-11 · chassis AT17#,ST170,CT17#,ET176 · catalogue 231120 · Japan

Discontinued model Data version 1993-06
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes
Exploded illustration 411165 42601 — WHEEL, DISC (48 parts) 42601A — WHEEL, DISC (FOR SPARE) (30 parts)
411165 · 2 callouts Full size ↗
78 parts on this figure
Part number Description Fitment Price
42601 — Wheel, Disc
42611-13070-03 note Wheel, Disc
1989-11 → 1990-05 ended
CT176,ET176 DX,SG ¥8,900
42611-13070-03 note Wheel, Disc
1988-05 → 1989-08 ended
CT176,ET176 DX,SG ¥8,900
42611-13070-03 note Wheel, Disc
1990-05 → 1992-11 ended
CT176,ET176 DX,SG ¥8,900
42611-13070-03 note Wheel, Disc
1989-08 → 1989-11 ended
CT176,ET176 DX,SG ¥8,900
42611-13070-03 note Wheel, Disc
1988-05 → 1992-11 ended
ET176 STD ¥8,900
42611-16170-03 note Wheel, Disc
1988-05 → 1992-11 ended
AT170,CT170 DX,SV ¥8,900
42611-20330-03 note Wheel, Disc
1988-05 → 1989-03 ended
AT171,ST170 S,SE ¥9,100
42611-20330-03 note Wheel, Disc
1989-08 → 1990-06 ended
ST170 SE CI ¥9,100
42611-20330-03 note Wheel, Disc
1990-05 → 1990-06 ended
ST170 SX ¥9,100
42611-20330-03 note Wheel, Disc
1990-05 → 1990-06 ended
CT170,ST170 SE ¥9,100
42611-20330-03 note Wheel, Disc
1989-08 → 1990-05 ended
AT171 S ¥9,100
42611-20330-03 note Wheel, Disc
1989-08 → 1990-05 ended
ST170 SGEXT ¥9,100
42611-20330-03 note Wheel, Disc
1989-03 → 1989-08 ended
AT171 S ¥9,100
42611-20330-03 note Wheel, Disc
1989-03 → 1989-08 ended
ST170 SE ¥9,100
42611-20330-03 note Wheel, Disc
1989-03 → —
ST170 SGEXT ¥9,100
42611-20331-01 note Wheel, Disc
1990-06 → 1992-04 ended
CT170,ST170 SE,SX ¥9,100
42611-20331-01 note Wheel, Disc
1990-05 → 1990-06 ended
CT170,ST170 SE,SX ¥9,100
42611-20331-01 note Wheel, Disc
1992-04 → 1992-11 ended
AT170 SGEXT;CT170,ST170 SE,SG,SGEXT,SX ¥9,100
42611-20410-03 note Wheel, Disc
1988-05 → 1992-08 ended
AT170,CT170 SG ¥8,900
42611-20410-03 note Wheel, Disc
1990-05 → 1992-11 ended
AT170,CT170 SV ¥8,900
42611-20470 note Wheel, Disc
1988-05 → 1992-08 ended
AT171 EFIS;AT171,175 GLIM,SE,SG,SGEXT ¥33,000
42611-20500-03 note Wheel, Disc
1989-03 → —
AT170,CT170,ST170 SG,SGEXT ¥8,700
42611-20500-03 note Wheel, Disc
1988-05 → 1990-06 ended
ST170 SGEXT EFI;AT170 (SE,SGEXT) +1 ¥8,700
42611-20500-03 note Wheel, Disc
1988-05 → 1990-06 ended
ST170 SX EFI ¥8,700
42611-20500-03 note Wheel, Disc
1988-05 → 1989-03 ended
CT170 SE;AT170,171,ST170 S,SE,SG,SGEXT ¥8,700
42611-20500-03 note Wheel, Disc
1989-08 → 1990-05 ended
AT170 4F SG ¥8,700
42611-20500-03 note Wheel, Disc
1989-08 → 1990-05 ended
AT170 (4FC,5F) SG ¥8,700
42611-20500-03 note Wheel, Disc
1989-08 → 1990-05 ended
AT170,171,CT170,ST170 S,SE,SGEXT ¥8,700
42611-20500-03 note Wheel, Disc
1989-08 → 1990-05 ended
ST170 SX ¥8,700
42611-20500-03 note Wheel, Disc
1988-05 → 1989-08 ended
ST170 SX ¥8,700
42611-20500-03 note Wheel, Disc
1989-03 → 1989-08 ended
AT170 (4FC,5F) SG ¥8,700
42611-20500-03 note Wheel, Disc
1989-03 → 1989-08 ended
AT170,171,CT170,ST170 S,SE,SGEXT ¥8,700
42611-20500-03 note Wheel, Disc
1989-03 → 1989-08 ended
AT170 4F SG ¥8,700
42611-20501-01 note Wheel, Disc
1990-05 → 1990-06 ended
AT170 SE,SGEXT;ST170 SGEXT,SX ¥8,900
42611-20501-01 note Wheel, Disc
1990-06 → 1992-11 ended
AT170 SE,SGEXT;ST170 SGEXT,SX ¥8,900
42611-20501-01 note Wheel, Disc
1990-12 → 1992-04 ended
CT170 SG ¥8,900
42611-20510 note Wheel, Disc
1989-05 → 1989-06 ended
ST170 SX ¥29,300
42611-20510 note Wheel, Disc
1990-12 → 1992-11 ended
CT170;AT170,ST170 SE,SGEXT,SV,SX ¥29,300
42611-20510 note Wheel, Disc
1989-05 → 1989-06 ended
AT170,175,CT170 SG,SV ¥29,300
42611-20510 note Wheel, Disc
1988-05 → 1989-03 ended
CT170 SE;AT170,171,ST170 S,SE,SG,SGEXT,SV,SX ¥29,300
42611-20510 note Wheel, Disc
1989-03 → 1990-05 ended
AT171,ST170 S,SGEXT ¥29,300
42611-20510 note Wheel, Disc
1989-03 → 1990-05 ended
AT170 (4FC,5F) SG ¥29,300
42611-20510 note Wheel, Disc
1989-03 → 1990-12 ended
ST170 (SE,SX) CI;AT170,CT170,ST170 (SE,SGEXT,SV,SX) +1 ¥29,300
42611-20510 note Wheel, Disc
1989-03 → 1990-05 ended
AT170 4F SG ¥29,300
42611-20630-03 note Wheel, Disc
1989-08 → 1990-05 ended
AT175 ¥10,500
42611-20630-03 note Wheel, Disc
1988-08 → 1989-08 ended
AT175 ¥10,500
42611-20630-03 note Wheel, Disc
1990-05 → 1992-08 ended
AT175 SG ¥10,500
42611-32100-03 note Wheel, Disc
1990-05 → 1992-08 ended
AT171,175 S,SE,SGEXT ¥10,500
42601A — Wheel, Disc (FOR SPARE)
42611-13070-03 note Wheel, Disc (FOR SPARE)
1988-05 → 1989-08 ended
CT176,ET176 DX,SG ¥8,900
42611-13070-03 note Wheel, Disc (FOR SPARE)
1989-08 → 1989-11 ended
CT176,ET176 DX,SG ¥8,900
42611-13070-03 note Wheel, Disc (FOR SPARE)
1989-11 → 1990-05 ended
CT176,ET176 DX,SG ¥8,900
42611-13070-03 note Wheel, Disc (FOR SPARE)
1990-05 → 1992-11 ended
CT176,ET176 DX,SG ¥8,900
42611-13070-03 note Wheel, Disc (FOR SPARE)
1988-05 → 1992-11 ended
ET176 STD ¥8,900
42611-16170-03 note Wheel, Disc (FOR SPARE)
1990-05 → 1992-11 ended
AT170,CT170 SV ¥8,900
42611-16170-03 note Wheel, Disc (FOR SPARE)
1990-05 → 1992-08 ended
AT170 DX ¥8,900
42611-16200 note Wheel, Disc (FOR SPARE)
1988-05 → 1992-11 ended
AT170,171,CT170,ST170 (DX,S,SE,SG,SGEXT,SV,SX) (CBR,CI,DSL,EFI) ¥6,700
42611-1A010 note Wheel, Disc (FOR SPARE)
1990-05 → 1992-08 ended
AT170,ST170 SE,SG,SGEXT ¥10,000
42611-20330-03 note Wheel, Disc (FOR SPARE)
1990-05 → 1990-06 ended
ST170 SX ¥9,100
42611-20330-03 note Wheel, Disc (FOR SPARE)
1990-05 → 1990-06 ended
CT170,ST170 SE ¥9,100
42611-20331-01 note Wheel, Disc (FOR SPARE)
1990-06 → 1992-04 ended
CT170,ST170 SE,SX ¥9,100
42611-20331-01 note Wheel, Disc (FOR SPARE)
1992-04 → 1992-11 ended
AT170 SGEXT;CT170,ST170 SE,SG,SGEXT,SX ¥9,100
42611-20331-01 note Wheel, Disc (FOR SPARE)
1990-05 → 1990-06 ended
CT170,ST170 SE,SX ¥9,100
42611-20410-03 note Wheel, Disc (FOR SPARE)
1990-12 → 1992-04 ended
AT170 SG ¥8,900
42611-20410-03 note Wheel, Disc (FOR SPARE)
1990-05 → 1992-11 ended
AT170,CT170 SV ¥8,900
42611-20410-03 note Wheel, Disc (FOR SPARE)
1992-04 → 1992-08 ended
AT170,CT170 SG ¥8,900
42611-20410-03 note Wheel, Disc (FOR SPARE)
1990-05 → 1990-12 ended
AT170,CT170 SG ¥8,900
42611-20410-03 note Wheel, Disc (FOR SPARE)
1990-12 → 1992-04 ended
CT170 SG ¥8,900
42611-20440 note Wheel, Disc (FOR SPARE)
1988-08 → 1992-08 ended
AT171 EFIS;AT171,175 GLIM,SE,SG,SGEXT ¥8,400
42611-20470 note Wheel, Disc (FOR SPARE)
1990-05 → 1992-08 ended
AT171,175 ¥33,000
42611-20500-03 note Wheel, Disc (FOR SPARE)
1990-05 → 1990-06 ended
ST170 SGEXT;AT170 SE,SGEXT ¥8,700
42611-20500-03 note Wheel, Disc (FOR SPARE)
1990-05 → 1990-06 ended
ST170 SX ¥8,700
42611-20501-01 note Wheel, Disc (FOR SPARE)
1990-12 → 1992-04 ended
CT170 SG ¥8,900
42611-20501-01 note Wheel, Disc (FOR SPARE)
1990-05 → 1992-11 ended
AT170 SE,SGEXT;ST170 SGEXT,SX ¥8,900
42611-20510 note Wheel, Disc (FOR SPARE)
1990-05 → 1990-12 ended
AT170,CT170,ST170 SE,SGEXT,SV,SX ¥29,300
42611-20510 note Wheel, Disc (FOR SPARE)
1990-12 → 1992-11 ended
CT170;AT170,ST170 SE,SGEXT,SV,SX ¥29,300
42611-20610 note Wheel, Disc (FOR SPARE)
1988-05 → 1992-08 ended
AT171 EFIS;AT171 GLIM ¥8,200
42611-20630-03 note Wheel, Disc (FOR SPARE)
1990-05 → 1992-08 ended
AT175 SG ¥10,500
42611-32100-03 note Wheel, Disc (FOR SPARE)
1990-05 → 1992-08 ended
AT171,175 S,SE,SGEXT ¥10,500
No quantity column: the factory catalogue records which parts a vehicle takes, never how many.
