Toyota Carina FF

1988-05 → 1992-11 · chassis AT17#,ST170,CT17#,ET176 · catalogue 231120 · Japan

Discontinued model Data version 1993-06

Dashed callouts are standard fasteners the factory draws but does not list as separate parts — there is no part number behind them.

15 parts on this figure

Part number	Description	Fitment	Price
76085 — Spoiler Sub-assy, Rear
08150-20080-02 note	Spoiler Sub-assy, Rear 1989-12 → 1990-05 ended	AT171 GLIM	¥57,300
08150-20080-03 note	Spoiler Sub-assy, Rear 1989-12 → 1992-08 ended	AT171 EFIS;AT171 GLIM	¥57,300
08150-20080-04 note	Spoiler Sub-assy, Rear 1989-12 → 1992-08 ended	AT171 EFIS;AT171 GLIM	¥57,300
08150-20080-05 note	Spoiler Sub-assy, Rear 1989-12 → 1990-05 ended	AT171 GLIM	¥57,300
08150-20080-07 note	Spoiler Sub-assy, Rear 1989-12 → 1990-05 ended	AT171 GLIM	¥57,300
08150-20080-08 note	Spoiler Sub-assy, Rear 1989-12 → 1992-08 ended	AT171 EFIS;AT171 GLIM	¥57,300
08150-20080-12 note	Spoiler Sub-assy, Rear 1990-05 → 1992-08 ended	AT171	¥57,300
08150-20080-13 note	Spoiler Sub-assy, Rear 1990-05 → 1992-08 ended	AT171	¥57,300
08150-20080-17 note	Spoiler Sub-assy, Rear 1989-12 → 1990-05 ended	AT171 GLIM	¥57,300
08150-20080-27 note	Spoiler Sub-assy, Rear 1990-05 → 1992-08 ended	AT171	¥57,300
08150-20080-37 note	Spoiler Sub-assy, Rear 1990-05 → 1992-08 ended	AT171	¥57,300
76871-21900 note	Spoiler Sub-assy, Rear 1990-05 → 1992-11 ended	ST170 SX	¥70,200
76871-21900 note	Spoiler Sub-assy, Rear 1990-05 → 1992-11 ended	AT170,CT170 SV	¥70,200
76871-21901	Spoiler Sub-assy, Rear 1990-05 → 1992-11 ended	ST170 SX	¥70,200
76871-21901	Spoiler Sub-assy, Rear 1990-05 → 1992-11 ended	AT170,CT170 SV	¥70,200

No quantity column: the factory catalogue records which parts a vehicle takes, never how many.
