Toyota Carina FF
1988-05 → 1992-11 · chassis AT17#,ST170,CT17#,ET176 · catalogue 231120 · Japan
Discontinued model
Data version 1993-06
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 86510 — Horn Assy, High Pitched | ||||
| 86510-20151 note |
Horn Assy, High Pitched
1988-05 → 1990-05
ended
|
AT17#,CT17#,ET176,ST170 | ¥3,420 | |
| 86510-20160 note |
Horn Assy, High Pitched
1988-05 → 1990-05
ended
|
AT17#,CT17#,ET176,ST170 | ¥3,240 | |
| 86510-20210 |
Horn Assy, High Pitched
1990-05 → 1992-11
ended
|
AT17#,CT17#,ET176,ST170 | ¥3,760 | |
| 86520 — Horn Assy, Low Pitched | ||||
| 86520-20161 note |
Horn Assy, Low Pitched
1988-05 → 1990-05
ended
|
AT17#,CT17#,ET176,ST170 | ¥3,420 | |
| 86520-20170 note |
Horn Assy, Low Pitched
1988-05 → 1990-05
ended
|
AT17#,CT17#,ET176,ST170 | ¥3,420 | |
| 86520-20220 |
Horn Assy, Low Pitched
1990-05 → 1992-11
ended
|
AT17#,CT17#,ET176,ST170 | ¥3,760 | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
