Toyota Carina FF
1988-05 → 1992-11 · chassis AT17#,ST170,CT17#,ET176 · catalogue 231120 · Japan
Discontinued model
Data version 1993-06
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 28515 — Resistor, Solenoid | ||||
| 28515-16020 |
Resistor, Solenoid
1988-05 → 1989-08
ended
|
4AGE AT171 | ¥11,200 | |
| 28515-74020 |
Resistor, Solenoid
1988-05 → 1990-05
ended
|
4SFI ST170 | ¥10,300 | |
| 28519 — Bracket, Solenoid Resistor | ||||
| 28519-16070 |
Bracket, Solenoid Resistor
1988-05 → 1989-08
ended
|
4AGE AT171 | ¥600 | |
| 28519-74020 |
Bracket, Solenoid Resistor
1988-05 → 1990-05
ended
|
4SFI ST170 | ¥520 | |
| 85910F — Relay, Computer (FOR EFI) | ||||
| 90987-02004 |
Relay, Computer (FOR EFI)
1988-05 → 1992-11
ended
|
AT17#,ST170 CI,EFI,EFIS | ¥2,330 | |
| 89421 — Sensor Assy, Vacuum (FOR E.F.I.) | ||||
| 89420-20120 |
Sensor Assy, Vacuum (FOR E.F.I.)
1988-05 → 1990-05
ended
|
AT171,175,ST170 | ¥9,400 | |
| 89420-20170 |
Sensor Assy, Vacuum (FOR E.F.I.)
1990-05 → 1992-11
ended
|
AT17#,ST170 | ¥9,400 | |
| 89422 — Sensor, Water Temperature (FOR E.F.I.) | ||||
| 89422-20010 |
Sensor, Water Temperature (FOR E.F.I.)
1988-05 → 1992-11
ended
|
AT17#,ST170 CI,EFI,EFIS | ¥2,420 | |
| 89424 — Sensor, Inlet Air Temperature (FOR E.F.I.) | ||||
| 89424-12010 |
Sensor, Inlet Air Temperature (FOR E.F.I.)
1988-05 → 1992-11
ended
|
AT17#,ST170 EFI,EFIS | ¥3,750 | |
| 89424-28010 |
Sensor, Inlet Air Temperature (FOR E.F.I.)
1988-05 → 1990-05
ended
|
ST170 | ¥6,600 | |
| 89428A — Switch, Water Temperature (FOR E.F.I) | ||||
| 89428-12110 |
Switch, Water Temperature (FOR E.F.I)
1988-08 → 1991-10
ended
|
AT175 4FC;AT171 4FC EFIS | ¥5,900 | |
| 89428-12110 |
Switch, Water Temperature (FOR E.F.I)
1991-10 → 1992-08
ended
|
AT175 4FC;AT171 EFIS | ¥5,900 | |
| 89452 — Sensor, Throttle Position (FOR E.F.I.) | ||||
| 89452-12010 |
Sensor, Throttle Position (FOR E.F.I.)
1988-05 → 1992-08
ended
|
AT171,175 (S,SE,SG,SGEXT) EFI | ¥14,100 | |
| 89452-12040 note |
Sensor, Throttle Position (FOR E.F.I.)
1988-05 → 1989-03
ended
|
AT171 GLIM | ¥13,200 | |
| 89452-12050 note |
Sensor, Throttle Position (FOR E.F.I.)
1988-05 → 1989-03
ended
|
AT171 GLIM | ¥13,400 | |
| 89452-12050 |
Sensor, Throttle Position (FOR E.F.I.)
1990-05 → 1992-08
ended
|
AT171 EFI | ¥13,400 | |
| 89452-14020 |
Sensor, Throttle Position (FOR E.F.I.)
1990-05 → 1992-11
ended
|
AT170,171,ST170 DX,S,SE,SG,SGEXT,SV,SX | ¥16,500 | |
| 89452-20080 |
Sensor, Throttle Position (FOR E.F.I.)
1988-05 → 1990-05
ended
|
ST170 | ¥11,800 | |
| 89462 — Switch, Start Injector Time | ||||
| 89462-20030 |
Switch, Start Injector Time
1988-05 → 1992-08
ended
|
AT171,175 EFI | ¥8,900 | |
| 89462-20040 note |
Switch, Start Injector Time
1988-05 → 1990-05
ended
|
ST170 | ¥8,900 | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
