Toyota Carina FF
1988-05 → 1992-11 · chassis AT17#,ST170,CT17#,ET176 · catalogue 231120 · Japan
Discontinued model
Data version 1993-06
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 83710 — Cable Assy, Speedometer Drive, NO.1 | ||||
| 83710-20710 |
Cable Assy, Speedometer Drive, NO.1
1988-05 → 1992-11
ended
|
AT170,CT17#,ET176 MTM | ¥2,960 | |
| 83710-20720 |
Cable Assy, Speedometer Drive, NO.1
1988-05 → 1992-11
ended
|
ET176 3FC | ¥2,960 | |
| 83710-20730 note |
Cable Assy, Speedometer Drive, NO.1
1988-08 → 1992-08
ended
|
AT175 5F | ¥2,870 | |
| 83710-20740 note |
Cable Assy, Speedometer Drive, NO.1
1988-08 → 1992-08
ended
|
AT175 4FC | ¥2,890 | |
| 83710-20750 note |
Cable Assy, Speedometer Drive, NO.1
1988-05 → 1992-11
ended
|
AT171,ST170;AT170,CT17# 4FC | ¥3,510 | |
| 83710-20760 note |
Cable Assy, Speedometer Drive, NO.1
1988-05 → 1992-11
ended
|
AT171,175,ST170;AT170,CT17# 4FC | ¥1,280 | |
| 83770 — Adapter Assy, Speedometer Cable | ||||
| 83770-17010 |
Adapter Assy, Speedometer Cable
1988-08 → 1992-08
ended
|
AT175 5F | ¥10,100 | |
| 83798 — Key, Speedometer Cable Adapter | ||||
| 83798-17010 |
Key, Speedometer Cable Adapter
1988-08 → 1992-08
ended
|
AT175 5F | ¥580 | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
