Toyota Carina FF

1992-08 → 1996-08 · chassis AT19#,CT19#,ST19# · catalogue 231130 · Japan

Discontinued model Data version 1997-01

Front Door Panel & Glass

37 part groups · 4 illustrations

PNC	Description
67001	Panel Sub-assy, Front Door, RH
67002	Panel Sub-assy, Front Door, LH
67111	Panel, Front Door, Outer RH
67112	Panel, Front Door, Outer LH
67151E	Reinforcement Sub-assy, Front Door Inside Panel, RH
67152	Reinforcement Sub-assy, Front Door Inside Panel, LH
67403F	Frame Sub-assy, Front Door, Rear Lower RH
67404F	Frame Sub-assy, Front Door, Rear Lower LH
67491A	Garnish, Front Door Lower Frame Bracket, RH
67492A	Garnish, Front Door Lower Frame Bracket, LH
67495A	Cover, Front Door Front Lower Frame, Upper RH
67496A	Cover, Front Door Front Lower Frame, Upper LH
67601	Board Sub-assy, Front Door Trim, RH
67601G	Plug, Hole(FOR FRONT DOOR TRIM BOARD)
67601H	Retainer, Door Trim, RH
67602	Board Sub-assy, Front Door Trim, LH
67602A	Retainer, Door Trim, LH
67651H	Grille, Speaker Door, RH
67652C	Grille, Speaker Door, LH
67697	Cover, Front Door Trim Pocket
67777	Pocket, Front Door Trim, RH
67778	Pocket, Front Door Trim, LH
67831	Cover, Front Door Service Hole, RH
67832	Cover, Front Door Service Hole, LH
67861	Weatherstrip, Front Door, RH
67862	Weatherstrip, Front Door, LH
67867C	Retainer, Front Door Weatherstrip, RH
67868C	Retainer, Front Door Weatherstrip, LH
67869B	Clip, Front Door Weatherstrip
68101	Glass Sub-assy, Front Door, RH
68102	Glass Sub-assy, Front Door, LH
68141C	Run, Front Door Glass, RH
68151C	Run, Front Door Glass, LH
68170	Weatherstrip Assy, Front Door Glass, Inner
68610	Check Assy, Front Door
68617	Pin, Front Door Check
68618	Bracket, Front Door Check Arm, RH

PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
