Toyota Lexus RC F
2014-09 → present · chassis USC10 · catalogue 246120 · Japan
Supported model
Data version 2019-05
Mudguard & Spoiler
46 part groups · 5 illustrations
Part groups
| PNC | Description |
|---|---|
| 52161G | Piece, Rear Bumper |
| 52161L | Piece, Front Spoiler |
| 52581J | Protector, Rear Bumper |
| 63265G | Gear, Rear Spoiler Drive |
| 63514D | Wire, Connector |
| 65631D | Plate, Rear Wheel House, Front RH |
| 65632D | Plate, Rear Wheel House, Front LH |
| 69705A | Link Sub-assy, Top Cover Lock Control, RH |
| 69706C | Link Sub-assy, Top Cover Lock Control, LH |
| 75392C | Retainer, Outside Moulding |
| 75392D | Retainer, Outside Moulding |
| 75867B | Clip, Rocker Panel Moulding |
| 75867G | Clip, Rocker Panel Moulding NO.2 |
| 76081 | Spoiler Sub-assy, Front |
| 76081B | Retainer, Front Spoiler |
| 76081C | Spoiler, Front Side RH |
| 76082A | Retainer Set, Front Spoiler |
| 76083B | Spoiler, Front Side LH |
| 76084 | Spoiler Set, Front |
| 76085 | Spoiler Sub-assy, Rear |
| 76085A | Cap(FOR REAR SPOILER) |
| 76781 | Tape, Rear Spoiler, Upper RH |
| 76781A | Tape, Rear Spoiler, Upper NO.1 |
| 76782 | Tape, Rear Spoiler, Upper LH |
| 76851 | Cover, Front Spoiler |
| 76853C | Retainer, Front Spoiler, NO.1 |
| 76854A | Retainer, Front Spoiler, NO.2 |
| 76857 | Retainer, Front Spoiler Side, RH |
| 76858 | Retainer, Front Spoiler Side, LH |
| 76863 | Retainer, Front Spoiler, Lower NO.2 RH |
| 76864 | Retainer, Front Spoiler, Lower NO.2 LH |
| 76867 | Retainer, Rear Spoiler Side, RH |
| 76868 | Retainer, Rear Spoiler Side, LH |
| 76871 | Spoiler, Rear |
| 76876B | Insert, Rear Spoiler |
| 76877A | Protector, Front Spoiler |
| 76887 | Seal, Rear Spoiler |
| 76887A | Seal, Rear Spoiler |
| 76887F | Seal, Rear Spoiler, NO.2 |
| 76887G | Seal, Rear Spoiler, NO.3 |
| 76889B | Seal, Rear Spoiler, NO.1 |
| 76893A | Cover, Rear Spoiler, RH |
| 76894 | Cover, Rear Spoiler, LH |
| 76895A | Spoiler, Rear Bumper, RH |
| 76896A | Spoiler, Rear Bumper, LH |
| 85760C | Motor Assy, Rear Spoiler |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
