Toyota Corona
1982-01 → 1998-04 · chassis TT14#,AT14#,ST140,RT141,YT140,CT14#,KT147 · catalogue 261150 · Japan
Discontinued model
Data version 1998-10
Transmission Gear (MTM)
109 part groups · 10 illustrations
Part groups
| PNC | Description |
|---|---|
| 33021 | Gear Set, Reverse |
| 33046 | Gear Sub-assy, Countershaft, 4TH |
| 33046A | Bearing(FOR COUNTERSHAFT 4TH GEAR) |
| 33103G | Ring, Hole Snap(FOR REAR BEARING SET) |
| 33311 | Shaft, Input |
| 33311A | Bearing (FOR INPUT SHAFT FRONT) |
| 33311B | Ring, Shaft Snap (FOR FRONT BEARING) |
| 33311C | Ring, Hole Snap (FOR NEEDLE ROLLER) |
| 33311D | Bearing, Input Shaft |
| 33311F | Spacer (FOR INPUT SHAFT) |
| 33311G | Ring, Shaft Snap (FOR FRONT BEARING) |
| 33318 | Piece, Gear Spline, NO.5 |
| 33321 | Shaft, Output |
| 33321A | Bearing (FOR OUTPUT SHAFT REAR) |
| 33321B | Ring, Shaft Snap (FOR OUTPUT SHAFT BEARING) |
| 33321C | Ring, Shaft Snap (FOR OUTPUT SHAFT BEARING) |
| 33321D | Ring, Shaft Snap (FOR CLUTCH HUB SET) |
| 33321P | Ring, Snap (FOR OUTPUT SHAFT CENTER BEARING) |
| 33321S | Spacer (FOR GEAR STOPPER) |
| 33321T | Spacer (FOR OUTPUT SHAFT) |
| 33321V | Bearing (FOR OUTPUT SHAFT CENTER) |
| 33321X | Ring, Shaft Snap (FOR OUTPUT SHAFT CENTER BEARING) |
| 33331 | Gear, Reverse |
| 33331A | Bearing (FOR REVERSE GEAR) |
| 33331B | Ring, Set (FOR REVERSE GEAR) |
| 33332 | Gear, 2ND |
| 33332B | Bearing, Needle Roller (FOR 2ND GEAR) |
| 33333 | Gear, 3RD |
| 33333A | Bearing, Needle Roller (FOR 3RD GEAR) |
| 33334 | Gear, 4TH |
| 33335 | Gear, 1ST |
| 33335C | Bearing, Needle Roller(FOR 1ST GEAR) |
| 33336 | Gear, 5TH |
| 33336A | Bearing, Needle Roller (FOR 5TH GEAR) |
| 33338 | Bush OR Bearing, 5TH Gear |
| 33338B | Bush, 5TH Gear |
| 33344 | Bush, Reverse Gear |
| 33344A | Key OR Ball, Reverse Gear Bearing |
| 33345 | Bush, 1ST Gear |
| 33345A | Ball (FOR 1ST GEAR BUSH) |
| 33349A | Washer, 4TH Gear |
| 33349B | Ball (FOR 4TH GEAR WASHER) |
| 33352 | Race, Reverse Gear Bearing Inner |
| 33352A | Key OR Ball, Reverse Gear Bearing Inner Race Lock |
| 33355 | Race, 1ST Gear Bearing Inner |
| 33355A | Key OR Ball, 1ST Gear Bearing Inner Race Lock |
| 33357 | Spring, Sub-gear Thrust, NO.1 |
| 33357A | Spring, Sub-gear Thrust, NO.2 |
| 33359A | Ball, 5TH Gear Bearing Inner Race Lock |
| 33361 | Hub, Transmission Clutch, NO.1 |
| 33361C | Spring Compression (FOR CLUTCH HUB) |
| 33362 | Hub, Transmission Clutch, NO.2 |
| 33362A | Ring, Shaft Snap (FOR CLUTCH HUB NO.2 SETTING) |
| 33363 | Sleeve, Transmission Hub, NO.1 |
| 33364 | Sleeve, Transmission Hub, NO.2 |
| 33365 | Key, Synchromesh Shifting, NO.1 |
| 33365A | Spring, Compression |
| 33366 | Key, Synchromesh Shifting, NO.2 |
| 33366D | Spring, Compression |
| 33367 | Ring, Synchronizer, NO.1 |
| 33368 | Ring, Synchronizer, NO.2 |
| 33369 | Ring, Synchronizer, NO.3 |
| 33371 | Spring, Synchromesh Shifting Key, NO.1 |
| 33376 | Spring, Synchromesh Shifting Key (FOR NO.3 CLUTCH HUB) |
| 33377 | Key, Synchromesh Shifting (FOR NO.3 CLUTCH HUB) |
| 33377B | Ring, Snap (FOR SYNCHROMESH SHIFTING KEY) |
| 33384A | Ring, Synchronizer, Outer NO.3 |
| 33385 | Retainer, Shifting Key |
| 33386 | Sub-gear, NO.1 |
| 33387 | Sub-gear, NO.2 |
| 33387A | Ring, Reverse Synchronizer |
| 33388A | Ring, Reverse Synchronizer Pull |
| 33389 | Ring, Synchronizer Cone |
| 33391 | Spring, Synchromesh Shifting Key, NO.2 |
| 33393 | Hub, Transmission Clutch, NO.3 |
| 33393A | Ring, Shaft Snap (FOR TRANSMISSION CLUTCH HUB NO.3) |
| 33394B | Key, Synchromesh Shifting, NO.3 |
| 33394C | Spring, Compression |
| 33395 | Sleeve, Transmission Hub, NO.3 |
| 33402 | Gear Sub-assy, Reverse Idler |
| 33402A | Bush OR Bearing (FOR REVERSE IDLER GEAR) |
| 33406 | Cover Sub-assy, Countershaft |
| 33411A | Bearing OR Roller(FOR COUNTER GEAR FRONT) |
| 33411D | Ring, Counter Gear Front Bearing Snap, NO.1 |
| 33411E | Nut(FOR COUNTER GEAR SHAFT) |
| 33411H | Bearing OR Roller(FOR COUNTER GEAR REAR) |
| 33411P | Bearing, Countershaft Center |
| 33411Q | Ring, Counter Gear Front Bearing Snap, NO.2 |
| 33411R | Ring, Snap, Counter Gear Rear Bearing |
| 33421 | Gear, Counter |
| 33425 | Gear, Countershaft Reverse |
| 33425A | Ring, Shaft Snap (FOR COUNTER GEAR) |
| 33428 | Gear, Countershaft 5TH |
| 33428A | Ring, Shaft Snap (FOR COUNTER 5TH GEAR) |
| 33431 | Spacer, Counter Gear, NO.1 |
| 33431A | Spacer, Counter Gear, NO.2 |
| 33435 | Washer, Counter Gear Case Side Thrust |
| 33451 | Shaft, Reverse Idler Gear |
| 33451E | Ring, E (FOR REVERSE IDLER GEAR SHAFT) |
| 33452 | Stopper, Reverse Idler Gear Shaft |
| 33453 | Spacer, Reverse Idler Gear Shaft |
| 33454 | Bolt, Shaft Retaining |
| 33455 | Washer, Reverse Idler Gear Thrust |
| 33462 | Washer, Reverse Idler Thrust |
| 33481 | Gear, Speedometer Drive (MTM) |
| 33481A | Key OR Ball, Speedometer Drive Gear (MTM) |
| 33481B | Ring OR Spacer (FOR MTM SPEEDOMETER DRIVE GEAR) |
| 33481D | Spacer (FOR SPEEDOMETER DRIVE GEAR) |
| 33481E | Clip (FOR SPEEDOMETER DRIVE GEAR) |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
