Toyota 86

2016-08 → present · chassis ZN6 · catalogue 264120 · Japan

Supported model Data version 2020-05
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Side Moulding

21 part groups · 2 illustrations

Illustrations

Figure 753375C 753375C 2016-08 → — Figure 753599C 753599C 2017-12 → —

Part groups

PNCDescription
67863F Weatherstrip, Front Door, NO.2 RH
67864F Weatherstrip, Front Door, NO.2 LH
67869M Clip, Door Weatherstrip
75551 Moulding, Roof Drip Side Finish, RH
75552 Moulding, Roof Drip Side Finish, LH
75555D Moulding, Roof Drip Side Finish, Center RH
75556C Moulding, Roof Drip Side Finish, Center LH
75561 Clip, Roof Drip Side Finish Moulding, NO.1
75601A Moulding Sub-assy, Front Fender, RH
75602A Moulding Sub-assy, Front Fender, LH
75651 Moulding, Quarter, Outside RH
75652 Moulding, Quarter, Outside LH
75850A Moulding Assy, Body Rocker Panel, RH
75853 Protector, Rear Fender, RH
75854 Protector, Rear Fender, LH
75860A Moulding Assy, Body Rocker Panel, LH
75866A Retainer, Rocker Panel Moulding
75866D Retainer, Rocker Panel Moulding
75867A Clip, Rocker Panel Moulding
75871A Clip (FOR FRONT FENDER MOULDING NO.1)
75895A Tape, Moulding, NO.1
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
