Toyota 86 Grmn
2016-02 → present · chassis GRMN86 · catalogue 265110 · Japan
Supported model
Data version 2016-02
Side Moulding
21 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 53861G | Duct, Front Fender Air, Upper RH |
| 53862B | Duct, Front Fender Air, Upper LH |
| 67863F | Weatherstrip, Front Door, NO.2 RH |
| 67864F | Weatherstrip, Front Door, NO.2 LH |
| 67869M | Clip, Door Weatherstrip |
| 75395A | Clip, Outside Moulding, NO.1 |
| 75551 | Moulding, Roof Drip Side Finish, RH |
| 75552 | Moulding, Roof Drip Side Finish, LH |
| 75555D | Moulding, Roof Drip Side Finish, Center RH |
| 75556C | Moulding, Roof Drip Side Finish, Center LH |
| 75561 | Clip, Roof Drip Side Finish Moulding, NO.1 |
| 75601A | Moulding Sub-assy, Front Fender, RH |
| 75602A | Moulding Sub-assy, Front Fender, LH |
| 75850A | Moulding Assy, Body Rocker Panel, RH |
| 75853 | Protector, Rear Fender, RH |
| 75854 | Protector, Rear Fender, LH |
| 75860A | Moulding Assy, Body Rocker Panel, LH |
| 75866A | Retainer, Rocker Panel Moulding |
| 75868B | Clip, Rocker Panel Moulding, NO.2 |
| 75895A | Tape, Moulding, NO.1 |
| 75896A | Tape, Moulding, NO.2 |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
