Toyota Corona
1987-12 → 1992-11 · chassis AT17#,ST17#,CT17#,ET176 · catalogue 271120 · Japan
Discontinued model
Data version 1993-06
Rear Axle Shaft & Hub
32 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 04438C | Boot Kit, Rear Drive Shaft |
| 04438D | Boot Kit, Rear Drive Shaft Inboard Joint |
| 42311 | Shaft, Rear Axle |
| 42311A | Seal, Oil(FOR REAR AXLE SHAFT) |
| 42311C | Bearing(FOR REAR AXLE SHAFT) |
| 42311D | Ring, Snap(FOR REAR AXLE SHAFT) |
| 42311F | Washer, Plate(FOR REAR AXLE SHAFT) |
| 42311G | Nut(FOR REAR AXLE SHAFT) |
| 42311Q | Bearing(FOR REAR AXLE SHAFT OUTER) |
| 42311R | Bearing(FOR REAR AXLE SHAFT INNER) |
| 42340 | Shaft Assy, Rear Drive |
| 42341A | Ring, Snap (FOR REAR DRIVE SHAFT) |
| 42343 | Cover, Outboard Joint End |
| 42346A | Clamp (FOR REAR DRIVE SHAFT OUTBOARD JOINT BOOT) |
| 42346B | Clamp, NO. 2 (FOR RR DRIVE SHAFT OUTBOARD JOINT BOOT) |
| 42347A | Clamp (FOR REAR DRIVE SHAFT INBOARD JOINT BOOT) |
| 42347B | Clamp, NO.2 (FOR REAR DRIVE SHAFT INBOARD JOINT BOOT) |
| 42350 | Joint Assy, Rear Drive Shaft Outboard |
| 42370 | Shaft Assy, Rear Drive Outboard Joint |
| 42403 | Drum Sub-assy, Rear Brake |
| 42418 | Cap, Rear Hub Grease |
| 42420A | Washer, Claw (FOR REAR AXLE SHAFT) |
| 42420B | Nut (FOR REAR AXLE SHAFT) |
| 42421 | Case, Rear Axle Bearing |
| 42421A | Bolt (FOR REAR AXLE BEARING CASE) |
| 42421C | Ring, O (FOR REAR AXLE BEARING CASE) |
| 42431 | Disc, Rear |
| 42450 | Hub & Bearing Assy, Rear Axle |
| 42451 | Deflector, Rear Wheel Bearing Dust, NO.1 |
| 42491 | Plug, Shoe Adjusting Hole (FOR PARKING BRAKE) |
| 42611E | Bolt, Hub (FOR REAR AXLE) |
| 43525A | Cap, Rear Wheel Adjusting Lock |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
