Toyota Premio/Allion

2001-12 → 2007-05 · chassis AZT240,NZT240,ZZT24# · catalogue 271150 · Japan

Discontinued model Data version 2007-10
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Parking Brake & Cable

12 part groups · 2 illustrations

Illustrations

Figure 460431F 460431F 2001-12 → — Figure 460432E 460432E 2001-12 → —

Part groups

PNCDescription
46200 Pedal Assy, Parking Brake Control
46201B Spring, Tension
46252 Pad, Parking Pedal
46341 Equalizer, Parking Brake
46410 Cable Assy, Parking Brake, NO.1
46420 Cable Assy, Parking Brake, NO.2
46430 Cable Assy, Parking Brake, NO.3
46439 Insulator, Parking Brake Cable Heat
46440 Cable Assy, Parking Brake, NO.4
46441 Nut, Wire Adjusting, NO.1
46458 Retainer, Cable
47149 Damper, Return Spring
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
