Toyota Camry/Vista
1986-08 → 1988-08 · chassis SV2#,VZV20,CV20 · catalogue 281130 · Japan
Discontinued model
Data version 1989-04
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 82981 — Wire, Headlamp Repair | ||||
| 82981-20010 |
Wire, Headlamp Repair
1986-08 → 1988-08
ended
|
CV20,SV2#,VZV20 | ¥950 | |
| 82982 — Wire, Clearance Lamp Repair | ||||
| 82982-20030 |
Wire, Clearance Lamp Repair
1986-08 → 1988-08
ended
|
SV2# HT | ¥950 | |
| 82982-32010 |
Wire, Clearance Lamp Repair
1987-04 → 1988-08
ended
|
VZV20 | ¥320 | |
| 82983 — Wire, Front Turn Signal Lamp Repair | ||||
| 82983-20010 |
Wire, Front Turn Signal Lamp Repair
1986-08 → 1988-08
ended
|
SV2# HT | ¥980 | |
| 82983-32020 |
Wire, Front Turn Signal Lamp Repair
1986-08 → 1988-08
ended
|
CV20,SV2# SED | ¥510 | |
| 82984 — Wire, Horn Repair | ||||
| 82984-20010 |
Wire, Horn Repair
1986-08 → 1988-08
ended
|
CV20,SV2#,VZV20 | ¥300 | |
| 82987 — Wire, Fog Lamp Repair | ||||
| 82987-30010 |
Wire, Fog Lamp Repair
1986-08 → 1988-08
ended
|
SV2# HT | ¥270 | |
| 82991 — Wire, Fusible Link Repair | ||||
| 82991-20050 note |
Wire, Fusible Link Repair
1986-08 → 1987-10
ended
|
CV20,SV2#,VZV20 | ¥520 | |
| 82991-20050 note |
Wire, Fusible Link Repair
1987-10 → 1988-08
ended
|
CV20,SV2#,VZV20 | ¥520 | |
| 82991-32050 note |
Wire, Fusible Link Repair
1987-04 → 1987-10
ended
|
SV21,VZV20 GT,PRO | ¥980 | |
| 82991-32050 note |
Wire, Fusible Link Repair
1987-10 → 1988-08
ended
|
SV21 GT | ¥980 | |
| 82991-32060 note |
Wire, Fusible Link Repair
1986-08 → 1987-10
ended
|
CV20 | ¥520 | |
| 82991-32060 note |
Wire, Fusible Link Repair
1987-10 → 1988-08
ended
|
CV20 | ¥520 | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
