Toyota Camry/Vista

1988-08 → 1990-07 · chassis SV2#,VZV20,CV20 · catalogue 281140 · Japan

Discontinued model Data version 1991-03
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Emblem & Name Plate (EXTERIOR & INTERIOR)

13 part groups · 2 illustrations

Illustrations

Figure MBN896D MBN896D 1988-08 → — Figure MBN897A MBN897A 1988-08 → —

Part groups

PNCDescription
75311 Emblem, Radiator Grille (OR FRONT PANEL)
75312B Emblem, Radiator Grille, NO.2
75321 Plate, Radiator Grille OR Front Panel Name
75324A Retainer, Radiator Grille Name Plate
75350 Emblem Assy, Front Fender
75351A Emblem, Front Fender
75441 Plate, Rear Name, NO.1
75444 Plate, Luggage Compartment Door, NO.4
75445 Plate, Luggage Compartment Door Name, NO.5
75446 Plate, Luggage Compartment Door Name, NO.6
75461 Plate, Rear Name, NO.2 (MODEL MARK)
75463 Plate, Rear Name, NO.4 (GRADE MARK)
75485 Plate, Back Window Name
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
