Toyota Camry/Vista
1990-07 → 1994-06 · chassis SV3#,VZV3#,CV30 · catalogue 281150 · Japan
Discontinued model
Data version 1994-11
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 16100 — Pump Assy, Engine Water | ||||
| 16100-69206 |
Pump Assy, Engine Water
1990-07 → 1991-05
ended
|
1VZFE VZV3# | ¥11,700 | |
| 16100-69295 |
Pump Assy, Engine Water
1990-07 → 1994-06
ended
|
2CT CV30 | ¥13,600 | |
| 16100-69305 |
Pump Assy, Engine Water
1991-05 → 1992-08
ended
|
1VZFE,4VZFE VZV3# | ¥14,700 | |
| 16100-69335 |
Pump Assy, Engine Water
1992-08 → 1994-06
ended
|
4VZFE VZV3# | ¥17,200 | |
| 16100-79175 |
Pump Assy, Engine Water
1990-07 → 1992-06
ended
|
3SGE SV32,33 | ¥14,400 | |
| 16100-79185 |
Pump Assy, Engine Water
1990-07 → 1994-06
ended
|
3SFE,4SFE SV3# | ¥14,400 | |
| 16100H — Ring, O(FOR WATER PUMP) | ||||
| 90301-37005 |
Ring, O(FOR WATER PUMP)
1990-07 → 1994-06
ended
|
3S#,4SFE SV3# | ¥260 | |
| 16110A — Bolt, Stud(FOR WATER OUTLET SETTING) | ||||
| 16193-63010 |
Bolt, Stud(FOR WATER OUTLET SETTING)
1990-07 → 1994-06
ended
|
3S#,4SFE SV3# | ¥350 | |
| 16110C — Pump Assy, Water, W/O Cover | ||||
| 16110-79025 |
Pump Assy, Water, W/O Cover
1990-07 → 1994-06
ended
|
3SFE,4SFE SV3# | ¥10,300 | |
| 16110-79115 |
Pump Assy, Water, W/O Cover
1990-07 → 1992-06
ended
|
3SGE SV32,33 | ¥9,800 | |
| 16124 — Gasket, Water Pump Cover | ||||
| 16124-74020 |
Gasket, Water Pump Cover
1990-07 → 1993-09
ended
|
3S#,4SFE SV3# | ¥520 | |
| 16124-88460 |
Gasket, Water Pump Cover
1993-09 → 1994-06
ended
|
3SFE,4SFE SV3# | ¥700 | |
| 16193 — Bolt, Stud(FOR WATER PUMP COVER) | ||||
| 90029-01500 |
Bolt, Stud(FOR WATER PUMP COVER)
1990-07 → 1994-06
ended
|
3S#,4SFE SV3# | ¥170 | |
| 16258 — Gasket(FOR HEATER RETURN) | ||||
| 16258-74020 |
Gasket(FOR HEATER RETURN)
1990-07 → 1993-09
ended
|
3SFE,4SFE SV3# | ¥580 | |
| 16258-74021 |
Gasket(FOR HEATER RETURN)
1993-09 → 1994-06
ended
|
3SFE,4SFE SV3# | ¥590 | |
| 16258-74030 |
Gasket(FOR HEATER RETURN)
1990-07 → 1992-06
ended
|
3SGE SV32,33 | ¥580 | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
