Toyota Camry/Vista
1990-07 → 1994-06 · chassis SV3#,VZV3#,CV30 · catalogue 281150 · Japan
Discontinued model
Data version 1994-11
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 82981 — Wire, Headlamp Repair | ||||
| 82981-32010 |
Wire, Headlamp Repair
1990-07 → 1992-06
ended
|
CV30,SV3#,VZV3# | ¥950 | |
| 82982 — Wire, Clearance Lamp Repair | ||||
| 82982-22050 note |
Wire, Clearance Lamp Repair
1990-07 → 1992-06
ended
|
CV30,SV3#,VZV3# | ¥980 | |
| 82982-32020 note |
Wire, Clearance Lamp Repair
1990-07 → 1992-06
ended
|
CV30,SV3#,VZV3# | ¥950 | |
| 82983 — Wire, Front Turn Signal Lamp Repair | ||||
| 82983-20020 |
Wire, Front Turn Signal Lamp Repair
1990-07 → 1992-06
ended
|
CV30,SV3#,VZV3# | ¥950 | |
| 82984 — Wire, Horn Repair | ||||
| 82984-20010 |
Wire, Horn Repair
1990-07 → 1992-06
ended
|
CV30,SV3#,VZV3# | ¥300 | |
| 82987 — Wire, Fog Lamp Repair | ||||
| 82987-20040 |
Wire, Fog Lamp Repair
1990-07 → 1992-06
ended
|
CV30,SV3# | ¥370 | |
| 82987-32010 |
Wire, Fog Lamp Repair
1990-07 → 1992-06
ended
|
VZV3# | ¥950 | |
| 82991 — Wire, Fusible Link Repair | ||||
| 82991-20080 |
Wire, Fusible Link Repair
1990-07 → 1992-06
ended
|
CV30,SV3#,VZV3# | ¥520 | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
