Toyota Windom
1996-08 → 2001-07 · chassis MCV2# · catalogue 282160 · Japan
Discontinued model
Data version 2002-01
Telephone & Mayday
22 part groups · 10 illustrations
Part groups
| PNC | Description |
|---|---|
| 82817R | Protector, Wiring Harness, NO.16 |
| 86090 | Telephone Assy |
| 86702 | Bracket Set, Telephone |
| 86714 | Controller, Telephone |
| 86722 | Cradle, Mobilephone |
| 86723 | Wire, Mobilephone |
| 86723A | Wire, Mobilephone |
| 86723B | Wire, Telephone Computer |
| 86724 | Guide, Curl Cord |
| 86726 | Cover, Mobilephone |
| 86726A | Cover, Mobilephone, NO.2 |
| 86726B | Cover, Mobilephone, NO.3 |
| 86726C | Cover, Mobilephone |
| 86730 | Microphone Assy, Telephone |
| 86760 | Antenna Assy, Telephone |
| 86771B | Charger, Portablephone Battery |
| 86773 | Wire, Portablephone |
| 86774 | Charger, Portablephone AC |
| 86775A | Handset, Portablephone |
| 86776 | Battery, Portablephone-s |
| 86777 | Battery, Mayday |
| 86779 | Strap, Portablephone |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
