Toyota Windom
2001-07 → 2006-03 · chassis MCV30 · catalogue 282170 · Japan
Discontinued model
Data version 2006-10
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 53111 — Grille, Radiator | ||||
| 53101-33120-A0 note |
Grille, Radiator
2001-07 → 2004-06
ended
|
MCV30 | ¥24,100 | |
| 53101-33120-B0 note |
Grille, Radiator
2001-07 → 2004-06
ended
|
MCV30 | ¥24,100 | |
| 53101-33120-C0 note |
Grille, Radiator
2001-07 → 2004-06
ended
|
MCV30 | ¥24,100 | |
| 53101-33120-D0 note |
Grille, Radiator
2001-07 → 2004-06
ended
|
MCV30 | ¥24,100 | |
| 53101-33120-H0 note |
Grille, Radiator
2001-07 → 2004-06
ended
|
MCV30 | ¥24,100 | |
| 53101-33120-J0 note |
Grille, Radiator
2001-07 → 2004-06
ended
|
MCV30 | ¥24,100 | |
| 53101-33140 |
Grille, Radiator
2004-06 → —
|
MCV30 | ¥25,300 | |
| 53396D — Seal, Radiator Grille | ||||
| 53396-30050 |
Seal, Radiator Grille
2001-07 → 2004-01
ended
|
MCV30 | ¥260 | |
| 53396-33010 |
Seal, Radiator Grille
2004-01 → 2004-06
ended
|
MCV30 | ¥260 | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
