Toyota Windom
2001-07 → 2006-03 · chassis MCV30 · catalogue 282170 · Japan
Discontinued model
Data version 2006-10
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 74110E — Receptacle Assy, Front Ash | ||||
| 74110-33180 |
Receptacle Assy, Front Ash
2001-07 → 2004-06
ended
|
MCV30 | ¥18,600 | |
| 74110-33250-D0 note |
Receptacle Assy, Front Ash
2004-06 → 2006-03
ended
|
MCV30 | ¥18,600 | |
| 74110-33250-E2 note |
Receptacle Assy, Front Ash
2004-06 → 2006-03
ended
|
MCV30 | ¥18,600 | |
| 74111 — Box, Front Ash Receptacle | ||||
| 74111-33040 |
Box, Front Ash Receptacle
2001-07 → 2004-06
ended
|
MCV30 | ¥2,880 | |
| 74111-33040 |
Box, Front Ash Receptacle
2004-06 → 2006-03
ended
|
MCV30 | ¥2,880 | |
| 74130 — Receptacle Assy, Rear Ash | ||||
| 74130-33020-A0 note |
Receptacle Assy, Rear Ash
2001-07 → 2004-06
ended
|
MCV30 | ¥4,180 | |
| 74130-33020-C0 note |
Receptacle Assy, Rear Ash
2001-07 → 2004-06
ended
|
MCV30 | ¥4,180 | |
| 74130-33020-A1 note |
Receptacle Assy, Rear Ash
2004-06 → 2006-03
ended
|
MCV30 | ¥4,180 | |
| 74130-33020-C0 note |
Receptacle Assy, Rear Ash
2004-06 → 2006-03
ended
|
MCV30 | ¥4,180 | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
