Toyota Supra
1993-05 → 2002-08 · chassis JZA80 · catalogue 291130 · Japan
Discontinued model
Data version 2003-01
Shift Lever & Retainer
82 part groups · 5 illustrations
Part groups
| PNC | Description |
|---|---|
| 33058 | Bracket Sub-assy, Shift Lock Solenoid |
| 33105A | Deflector Sub-assy, Extension Housing Oil(MTM) |
| 33250A | Lever Assy, Shift, Inner NO.2 |
| 33281F | Pin, Lever Lock (FOR FLOOR SHIFT) |
| 33282D | Pin, Lever Lock, NO.2 |
| 33501G | Bush (FOR FLOOR SHIFT CONTROL SHAFT) |
| 33502 | Plate Sub-assy, Shift Lever |
| 33502A | Collar (FOR FLOOR SHIFT SETTING) |
| 33503A | Collar(FOR SHIFT LEVER) |
| 33503F | Lever Sub-assy, Shift(FOR FLOOR SHIFT) |
| 33503P | Ring, O(FOR SHIFT LEVER) |
| 33504C | Screw (FOR SHIFT LEVER KNOB SETTING) |
| 33504F | Knob Sub-assy, Shift Lever |
| 33506A | Bolt (FOR CONTROL SHIFT LEVER RETAINER) |
| 33506F | Retainer Sub-assy, Control Shift Lever (FOR FLOOR SHIFT) |
| 33506W | Plug, Breather (FOR SHIFT LEVER RETAINER) |
| 33511 | Shaft, Control (FOR FLOOR SHIFT) |
| 33511C | Collar (FOR CONTROL SHAFT) |
| 33513H | Yoke, Control Shaft, NO.1 |
| 33520A | Shaft Assy, Floor Shift Control |
| 33525G | Ring, Shift Lever |
| 33529C | Bolt, Shift Lever |
| 33530F | Lever Assy, Shift (FOR FLOOR SHIFT) |
| 33530J | Ring, O (FOR SHIFT LEVER) |
| 33531 | Boot, Dust (FOR CONTROL SHIFT LEVER) |
| 33539 | Cushion, Shift Lever Anti-rattle |
| 33544 | Insert, Shift Lever, NO.1 |
| 33548F | Bush, NO.1, Shift Lever (FOR FLOOR SHIFT) |
| 33550A | Collar For Floor Shift) |
| 33550D | Bulb, Position Indicator Lamp |
| 33550E | Cap, Position Indicator Lamp |
| 33555 | Boot, Shift Lever |
| 33555B | Boot, Shift & Select Lever |
| 33555F | Boot, Shift & Select Lever, NO.2 |
| 33555G | Boot, Shift & Select Lever, NO.3 |
| 33556F | Seat, Transmission Shift Lever Ball |
| 33556K | Ring, O, N0.1 (FOR TRANSMISSION SHIFT LEVER BALL SEAT) |
| 33556L | Ring, O, N0.2 (FOR TRANSMISSION SHIFT LEVER BALL SEAT) |
| 33559A | Nut, Shift Lever, NO.1 |
| 33563 | Button, Shift Lock Release |
| 33563A | Spring, Compression (FOR SHIFT LOCK RELEASE BUTTON) |
| 33571F | Bracket, Control Shaft, Lower NO.2 |
| 33574F | Retainer, Dust Seal (FOR FLOOR SHIFT) |
| 33575 | Retainer, Control Shift Lever (FOR FLOOR SHIFT) |
| 33575A | Bush, NO.1 (FOR CONTROL SHIFT LEVER RETAINER) |
| 33575B | Bush, NO.2 (FOR CONTROL SHIFT LEVER RETAINER) |
| 33582B | Stopper, Shift Lock Plate (FOR FLOOR SHIFT) |
| 33589 | Link, Shift Lock Solenoid |
| 33595 | Bracket, Shift Lock Computer |
| 33597B | Seat, Shift Lever, NO.1 (FOR FLOOR SHIFT) |
| 33622 | Cover, Shift Lever Knob, NO.1 |
| 33623 | Button, Shift Lever Knob |
| 33625 | Sleeve, Shift Lever Knob |
| 33626 | Stopper, Shift Lever Button |
| 33631 | Rod, Detent |
| 33631A | Spring, Compression (FOR DETENT ROD) |
| 33631B | Pin, Slotted Spring (FOR DETENT ROD) |
| 33631D | Pin, Grooved (FOR DETENT ROD) |
| 33632 | Rod, Detent, NO.2 |
| 33661 | Housing, Shift Lever Guide |
| 33662A | Cushion, Shift Lever Guide |
| 33675 | Rod, Transmission Control (FOR FLOOR SHIFT) |
| 33675A | Pin, W/Hole (FOR TRANSMISSION CONTROL ROD) |
| 33675B | Bush (FOR TRANSMISSION CONTROL ROD) |
| 33675C | Grommet (FOR TRANSMISSION CONTROL ROD) |
| 33723F | Swivel, Connecting Rod (FOR FLOOR SHIFT) |
| 33723G | Bush (FOR FLOOR SHIFT CONTROL SHAFT) |
| 33723H | Grommet (FOR FLOOR SHIFT CONTROL SHAFT) |
| 33872 | Link, Shift Lock Release, NO.2 |
| 33873 | Link, Shift Lock Release, NO.3 |
| 33886 | Stopper, Shift Lever |
| 35469L | Spacer, Shift Lever |
| 35906 | Wire Sub-assy, Indicator Lamp |
| 35907 | Housing Sub-assy, Position Indicator (FOR FLOOR SHIFT) |
| 35921 | Plate, Control Position Indicator |
| 35953 | Guide, Position Indicator Light |
| 35954 | Sheet, Position Indicator |
| 35974 | Housing, Position Indicator, Lower |
| 35975 | Cover, Slide (FOR POSITION INDICATOR) |
| 35976 | Cover, Slide, NO.2 (FOR POSITION INDICATOR) |
| 35976B | Cover, Shift Lever Knob (FOR FLOOR SHIFT) |
| 35983 | Bracket (FOR SHIFT LEVER PLATE) |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
