Toyota Mark 2

1988-08 → 1995-12 · chassis GX81,LX80,MX83,SX80,YX80,JZX81 · catalogue 311160 · Japan

Discontinued model Data version 1997-06
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Radiator Grille

7 part groups · 2 illustrations

Illustrations

Figure NB0857D NB0857D 1988-08 → — Figure NB0858D NB0858D 1988-08 → —

Part groups

PNCDescription
53111 Grille, Radiator
53112C Grille, Radiator, Lower RH
53113C Grille, Radiator, Lower LH
53131H Door, Headlamp, Upper RH
53132H Door, Headlamp, Upper LH
53133A Door, Headlamp, Lower RH
53134A Door, Headlamp, Lower LH
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
