Toyota Cresta
1980-03 → 1984-07 · chassis GX5#,61,LX60,MX51,61,SX60,TX50 · catalogue 313140 · Japan
Discontinued model
Data version 1985-03
Rear Seat & Seat Track
18 part groups · 2 illustrations
Part groups
| PNC | Description |
|---|---|
| 71075B | Cover, Rear Seat Cushion (FOR BENCH TYPE) |
| 71077B | Cover, Rear Seatback (FOR BENCH TYPE) |
| 71460B | Cushion Assy, Rear Seat (FOR BENCH TYPE) |
| 71460T | Pad Sub-assy, Rear Seat Cushion, NO.1 |
| 71460U | Pad Sub-assy, Rear Seat Cushion, NO.2 |
| 71480B | Back Assy, Rear Seat (FOR BENCH TYPE) |
| 71480C | Pad Sub-assy, Rear Seatback, NO.1 (FOR BENCH TYPE) |
| 71650 | Spring Assy, Rear Seat Cushion |
| 71670 | Spring Assy, Rear Seatback(FOR BENCH SEAT) |
| 71671 | Pad, Rear Seatback Silencer, A |
| 71681 | Pad, Rear Seatback Corner, A |
| 71812B | Clip(FOR REAR SEAT CUSHION COVER) |
| 71893 | Garnish, Rear Seatback Side, Lower RH |
| 71953 | Pad, Rear Seat Headrest |
| 71970 | Headrest Assy, Rear Seat |
| 72693 | Hook, Rear Seat Cushion Lock |
| 72830 | Armrest Assy, Rear Seat, Center |
| 72830B | Bush(FOR REAR SEAT CENTER ARMREST) |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
