Toyota Cresta
1988-08 → 1992-10 · chassis GX81,LX80,MX83,SX80,YX80,JZX81 · catalogue 313160 · Japan
Discontinued model
Data version 1993-06
Air Purifier OR Ion Generator
15 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 88901 | Motor Sub-assy, Air Purifier |
| 88904A | Accessory Sub-assy, Air Purifire |
| 88905 | Wire Sub-assy, Air Purifier, NO.1 |
| 88912 | Fan, Air Purifier |
| 88915 | Resistor, Air Purifier |
| 88920A | Purifier Assy, Air |
| 88926 | Filter, Air Purifier |
| 88927 | Filter, Air Purifier, NO.2 |
| 88928A | Case, Air Purifier Filter |
| 88929A | Pin, Air Purifier Duct |
| 88930A | Switch Assy, Air Purifier |
| 88931 | Sensor, Smoke |
| 88932 | Cover, Smoke Sensor |
| 88950 | Amplifier Assy, Air Purifier |
| 88960B | Resistor Assy, Air Purifire |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
