Toyota Cresta

1992-10 → 1996-09 · chassis GX90,JZX9#,LX90,SX90 · catalogue 313170 · Japan

Discontinued model Data version 1997-06
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Suspension Crossmember & Under Cover

12 part groups · 2 illustrations

Illustrations

Figure 510659 510659 1992-10 → — Figure 511700 511700 1992-10 → —

Part groups

PNCDescription
51201 Crossmember Sub-assy, Front Suspension
51202C Crossmember Sub-assy, Front Suspension, Lower
51206A Member Sub-assy, Rear Suspension
51229C Plate, Suspension Member Set
51441 Cover, Engine Under, NO.1
51447B Protector, Oil Pan
51967 Hook, Transport, Rear
52205G Cushion Sub-assy, Body Mounting, Lower
52271D Cushion, Rear Suspension Member Body Mounting, Front
52273 Stopper, Rear Suspension Member, Lower
52279 Retainer, Rear Suspension Member Cushion
52285 Bolt, Differential Support Member Mounting, NO.1
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
