Toyota Cresta
1992-10 → 1996-09 · chassis GX90,JZX9#,LX90,SX90 · catalogue 313170 · Japan
Discontinued model
Data version 1997-06
Navigation & Front Monitor Display
19 part groups · 3 illustrations
Part groups
| PNC | Description |
|---|---|
| 86010 | Tuner Assy, Television |
| 86050C | Antenna Assy, Television |
| 86102A | Selector Sub-assy, Antenna |
| 86110A | Controller Assy, Multi-display |
| 86111 | Multi-display |
| 86112 | Computer, Multi-display (COMPUTER CRT DISPLAY) |
| 86115 | Tray, Multi-display Computer |
| 86117 | Bracket, Multi-display Controller, A |
| 86118 | Bracket, Multi-display Controler, B |
| 86191 | Terminal, Video(VIDEO ADAPTER) |
| 86203A | Wiring Sub-assy, Television |
| 86271 | Disc, Disc Player |
| 86808 | Cord Sub-assy, Navigation Antenna, NO.1 |
| 86841 | Computer, Navigation |
| 86851 | Receiver, Navigation |
| 86860 | Antenna Assy, Navigation |
| 86860A | Antenna, Navigation |
| 86862 | Bracket, Navigation Antenna |
| 89467 | Bracket, Navigation Sensor |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
